70*70*15mm DC Computer Case CPU Cooling Fan
- SHENZHEN
- Credit Card
You May Like
Product Details
| Electric Current Type | DC | Mounting | Other, ACCORDING TO YOU DEMANDS | |
| Blade Material | Plastic | Place of Origin | Guangdong, China | |
| Model Number | YM1207PHS(B)1 | Voltage | 12V | |
| Power | 2.64W | Air Volume | 34.4CFM | |
| Speed | 4000RPM | Certification | CE, UL, ROHS |
Product Description
Specifications
70*70*15mm Computer Case Cooling Fan:1.Motor protection 2.High static pressure
3.Low noise and long life 4.Good quality
70*70*15mm DC Computer Case CPU Cooling Fan
General Specifications
Frame | Plastic(UL94v-0) |
Impeller | Plastic(UL94v-0) |
Bearing type | Dual Ball Bearing |
Leadwire | UL1007AWG#24 or Equivalent (+):Red(-):Black |
Motor | Impedance Protected and Reverse Polarity Protected |
Expected Life
1.Ball Bearing 50,000 hours(40°c)
2.Sleeve Bearing 30,000 hours(40°c)
Allowable Ambient Temperature Range
1.-10°c~+70°c (Operating)
2.-40°c~+70°c (Storage)
3.(non-condensing environment)
| Size(mm) | Model | Rated voltage | Operating Voltage Range | Current amp | Rated Input Power | Speed | Max air Flow | Max Static Pressure | Noise Level | Weight |
| (v) | (v) | (Amp) | (Watt) | (rpm) | (CFM) | (Inch-H2o) | (dB-A) | (g) | ||
| 70 *70 * 15 | YM1207PHS(B)1 | 12 | 7.0 to 13.8 | 0.22 | 2.64 | 4000 | 34.04 | 0.2 | 36 | 48 |
| YM1207PHS(B)2 | 12 | 7.0 to 13.8 | 0.17 | 2.04 | 3500 | 29.89 | 0.13 | 33 | 48 | |
| YM1207PHS(B)3 | 12 | 7.0 to 13.8 | 0.12 | 1.44 | 3000 | 25.05 | 0.09 | 28 | 48 | |
| YM2407PHS(B)1 | 24 | 14.0 to 27.6 | 0.12 | 2.88 | 4000 | 34.04 | 0.2 | 36 | 48 | |
| YM2407PHS(B)2 | 24 | 14.0 to 13.8 | 0.09 | 2.16 | 3500 | 29.89 | 0.13 | 33 | 48 | |
| YM2407PHS(B)3 | 24 | 14.0 to 27.6 | 0.07 | 1.68 | 3000 | 25.05 | 0.09 | 28 | 48 |
Alibaba: http://topfan-china.en.china.cn
Founded in 1996 in Shenzhen China, we, Shenzhen Topfan-China Technology Co., Ltd, is professional manufacturer and researcher on dc brushless fans and ac fans. Our products are ISO9000, UL, CE, RoHS and TUV certificated and good sellers both at home and abroad, including European, North American, Asia(Korea and India) and so on. The products, including brushless fans, cross flow fans, blower fans, centrifugal fans, dc brushless motor, shades pole and RC ac fans, are being widely used in the information technology, network communications as well as industrial production equipment, medical equipment, home appliances and others. Based on mutual benefit and development, we always make our biggest efforts to do everything better for our customers.
