Home > Products > Centrifugal Fan > 24V DC centrifugal exhaust fan brushless blower 60*60*18mm
24V DC centrifugal exhaust fan brushless blower 60*60*18mm
USD $1.5 - $5
/ Piece
500 Pieces(Min.Order)
- 20000 Piece / Pieces per Month
- shenzhen
- T/T
You May Like
-
DC12V High Temperture blower cooling fan 97 *94 *32mm
-
18mm Micro DC Blower Fan 5v Axially - Grooved Bearing
-
4.7 inch 24v dc centrifugal blower fan for equipment 120*120*32mm
-
AC 120V Housing Centrifugal fan Diameter 150MM / Blower Fan Motor
-
3.3V - 5V Micro DC Brushless Blower Fan 18x18x4mm
-
12V 24V DC Centrifugal Blower Fan With PWM And FG 100*25mm
Product Details
| Electric Current Type | DC | Blade Material | Plastic | |
| Mounting | Other, blower fan | Place of Origin | Guangdong, China | |
| Brand Name | MX/OEM/ODM | Model Number | MX6018GB(S)H1 | |
| Power | 1.2-4.8W | Voltage | 5V,12V,24V | |
| Air Volume | 4.06-5.89CFM | Speed | 3500RPM-5500RPM | |
| Certification | CCC, CE, ROHS, UL, Other, UL, CE, CCC, CE, ROHS, UL, ISO9000, UL ,CE, RoHS, TUV | After-sales Service Provided | No overseas service provided |
Product Description
24V DC centrifugal exhaust fan brushless blower 60*60*18mm
General Specifications:
Frame | plastic(UL94v-0) |
Impeller | plastic(UL94v-0) |
Bearing type | Dual Ball Bearing |
Leadwire | UL1007AWG#26 or Equivalent (+):Red(-):Black |
Motor | Impedance Protected and Reverse Polarity Protected |
Voltage | 5V,12V,24V |
Expected Life:
1.Ball Bearing 50,000 hours(40°c)
2. Sleeve Bearing 30,000 hours (40°c)
Allowable Ambient Temperature Range
1.-10°c~+70°c (Operating)
2.-40°c~+70°c (Storage)
3.(non-condensing environment)
Specifications:
| Model | Bearing Type | Rated Voltage | Operating Voltage | Input Current | Input Power | Speed | Max Air Flow | Max Static Pressure | Noise | Weight | ||
| Part No. | B.S | VDC | VDC | Amp | Watt | RPM | CFM | m3/min | Inch-H2O | pa | dB-A | g |
| MX6018GB(S)H5 | B.S | 5 | 3.5-5.5 | 0.36 | 1.80 | 4500 | 5.09 | 0.14 | 0.42 | 104.54 | 39 | 41 |
| MX6018GB(S)M5 | B.S | 5 | 3.5-5.5 | 0.24 | 1.20 | 3500 | 4.06 | 0.11 | 0.25 | 62.37 | 34 | 41 |
| MX6018GB(S)H1 | B.S | 12 | 7.0-13.8 | 0.30 | 3.60 | 5500 | 5.89 | 0.17 | 0.71 | 176.81 | 43 | 41 |
| MX6018GB(S)M1 | B.S | 12 | 7.0-13.8 | 0.20 | 2.40 | 4500 | 5.09 | 0.14 | 0.42 | 104.54 | 39 | 41 |
| MX6018GB(S)L1 | B.S | 12 | 7.0-13.8 | 0.15 | 1.80 | 3500 | 4.06 | 0.11 | 0.25 | 62.37 | 34 | 41 |
| MX6018GB(S)H2 | B.S | 24 | 14.0-27.6 | 0.20 | 4.80 | 5500 | 5.89 | 0.17 | 0.71 | 176.81 | 43 | 41 |
| MX6018GB(S)M2 | B.S | 24 | 14.0-27.6 | 0.12 | 2.88 | 4500 | 5.09 | 0.14 | 0.42 | 104.54 | 39 | 41 |
| MX6018GB(S)L2 | B.S | 24 | 14.0-27.6 | 0.08 | 1.92 | 3500 | 4.06 | 0.11 | 0.25 | 62.37 | 34 | 41 |
