Industrial 12 Volt DC Blower Fan with PWM / 3 Inch Car Fan 75mm*75mm*30mm
- shenzhen
- T/T
You May Like
Product Details
| Electric Current Type | DC | Blade Material | Plastic | |
| Mounting | Free Standing | Place of Origin | Guangdong, China | |
| Brand Name | MX/OEM/ODM | Model Number | MX7530GB(S)H1 | |
| Power | 7.20 | Voltage | 12V/24V, 12V/24V | |
| Air Volume | 15.90 | Speed | 4500rpm | |
| Certification | CCC, CE, CSA, ROHS, UL | After-sales Service Provided | No overseas service provided |
Product Description
Industrial 12 Volt DC Blower Fan with PWM / 3 Inch Car Fan 75mm×75mm×30mm
Applications
1. Ventilation Equipment & System
2. Heating Equipment & System
3. Air Conditioner
4. Refrigeration equipment
5. MDBS(Mobile Data Base Station)
6. Telecom power supply station
Description:
1. High speed , Middle speed, Low speed
2. Plastic Frame or Die-Cast Aluminum Frame and Plastic impeller
3. 5 blades 7 blades or 9 blades
4. 5V DC 12V DC 24V DC or 48V DC
5. Ball bearing or Sleeve bearing or Hydraulic bearing
6. Terminal or Lead wire
7. Waterproof explosion proof or high proof are can be satisfied.
A: Specifications:
| Model | Bearing Type | Rated Voltage | Operating Voltage | Input Current | Input Power | Speed | Max Air Flow | Max Static Pressure | Noise | Weight | ||
| Part No. | B.S | VDC | VDC | Amp | Watt | RPM | CFM | m3/min | Inch-H2O | pa | dB-A | g |
| MX7530GB(S)H1 | B.S | 12 | 7.0-13.8 | 0.60 | 7.20 | 4500 | 15.64 | 0.44 | 1.06 | 263.31 | 51 | 69 |
| MX7530GB(S)M1 | B.S | 12 | 7.0-13.8 | 0.45 | 5.40 | 4000 | 13.67 | 0.39 | 0.81 | 201.13 | 46 | 69 |
| MX7530GB(S)L1 | B.S | 12 | 7.0-13.8 | 0.35 | 4.20 | 3500 | 12.25 | 0.35 | 0.60 | 149.55 | 40 | 69 |
| MX7530GB(S)H2 | B.S | 24 | 14.0-27.6 | 0.30 | 7.20 | 4500 | 15.64 | 0.44 | 1.06 | 263.31 | 51 | 69 |
| MX7530GB(S)M2 | B.S | 24 | 14.0-27.6 | 0.25 | 6.00 | 4000 | 13.67 | 0.39 | 0.81 | 201.13 | 46 | 69 |
| MX7530GB(S)L2 | B.S | 24 | 14.0-27.6 | 0.20 | 4.80 | 3500 | 12.25 | 0.35 | 0.60 | 149.55 | 40 | 69 |
B: (Main Materials, Parts Specification):
Bearing | ♦ (Dual Ball Bearing) | ◊ | (Sleeve Bearing) | |||||||
Frame | ♦ | PBT of UL94V-0. | ◊ | Die-cast Aluminum Alloy | ||||||
Impeller | ♦ | PBT of UL94V-0. | ◊ | Steel | ||||||
Bobbin | PBT of UL94V-0. | |||||||||
Lead Wire | ♦ | Red(+) | ♦ | Black(-) | ♦ | Blue(PWM) | UL 1571 28# | |||
◊ | Yellow(FG) | ◊ | White(RD) | 2 wires 100±10mm | ||||||
Connector | No | |||||||||
Tube | No | |||||||||
C: Electrical Specification:
ITEM |
| Specification. Condition | |||
Locked Rotor Protection | ◊ | Safety Condition | |||
| Auto power off after locked at rated voltage for 1sec | ||||
Polarity Protection | ♦ | Open circuit when Vcc&GND are exchanged | |||
◊ | Circuit won’t be burned within 5 seconds when Vcc &GND are exchanged | ||||
Insulation Resistance | 10MΩ Between unshielded wire and frame at 500VDC/min | ||||
Dielectric Strength | 5mA Max/ Measured b/w lead wire(+)and frame at 500VAC/min | ||||
Special Function | ◊ | Soft Start | ◊ | Current Limiter | |
Dimensions (Unit:mm)
