Home > Products > Axial fan > 80x80x25mm EC Axial Fan

80x80x25mm EC Axial Fan

FOB Price

USD $1 - $8 / Piece

1000 Pieces(Min.Order)

Supply Ability 100000 Piece / Pieces per Month
Port shenzhen
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Electric Current Type	Other, EC	Mounting	Other, cooling fan
Blade Material	Plastic	Place of Origin	Guangdong, China
Brand Name	topfan/OEM	Model Number	M075AA2H
Voltage	115V,115V/230V	Power	6W
Air Volume	36.5CFM	Speed	3000RPM
Certification	CE, CSA, GS, ROHS, UL	After-sales Service Provided	Overseas service center available

Product Description

Specifications

1. Voltage:AC - DC
2. Green Environmental Production
3. Average energy savings of 30%
4. Customizable

80x80x25mm Cost-efficient 115V/230V EC Axial Fan :

,,Specification

Model	Dimensions(mm)			Bearing System	Rated Voltage	Freq.	Operation Voltage	Rated Current	Power	Rated Speed	Air Flow	Air Pressure	Noise Level	Weight
Model	Size	Pitch-row	Bore Diameter	Bearing System	VAC	Hz	VAC	A	W	RPM	CFM	mmH₂O	dBA	g
M075AA1H	808025	71.5±0.3	4.4±0.3	Ball	115	60	98-138	0.20	6.0	3000	36.5	3.5	32	76
M075AA1H	808025	71.5±0.3	4.4±0.3	Ball	115	60	98-138	0.15	4.5	2500	32.0	2.5	27	76
M075AA1H	808025	71.5±0.3	4.4±0.3	Ball	115	60	98-138	0.10	3.5	2000	25.0	1.6	22	76
M075AA2H	808025	71.5±0.3	4.4±0.3	Ball	230	50	198-264	0.15	6.0	3000	36.5	3.5	32	76
M075AA2H	808025	71.5±0.3	4.4±0.3	Ball	230	50	198-264	0.10	4.5	2500	32.0	2.5	27	76
M075AA2H	808025	71.5±0.3	4.4±0.3	Ball	230	50	198-264	0.07	3.5	2000	25.0	1.6	22	76

,,Shipment

1. FOB Shenzhen or HongKong (mass production)

2. DHL,UPS,FEDEX,TNT or any other international express (sample or small quantity)

<<<More details can be discussed.>>>

,,Payment

T/T and Western Union

1. The payment for the high value sample will be charged.

2. The payment for the low value sample is free, but the freight should be paid by you.

,,Delivery Time

Generally, 500~1000pics 10 days after confirming the PI

,,Our Company

Web:

Alibaba: http://topfan-china.en.china.cn

Shenzhen Topfan-China Development Technology Co., Ltd, founded in 1996 in Shenzhen China, is professional manufacturer on dc brushless fans and ac fans. Products are ISO9000, UL, CE, RoHS and TUV certificated and good sellers both at home and abroad, including Europe, North America, Asia(Korea and India) etc. The products, including brushless fans, cross flow fans, blower fans, centrifugal fans, dc brushless motor, shades pole and RC ac fans etc, are being widely used in the information technology, network communications as well as industrial production equipment, medical equipment, home appliances and others.

Based on mutual benefit and development, we'll make our biggest efforts to do everything better for our customers.
