24V dc fan 200 X 200 X 60mm
USD $1 - $15
/ Piece
500 Pieces(Min.Order)
- 700 Piece / Pieces per Month
- SZ
- T/T
You May Like
-
30x30x7mm 5V DC Blower Fan / Snail Fan 12V / Small DC Motor / Mini Centrifugal Fan
-
mini dc blower fan 75x75x30mm with high temperature
-
60mm car turbo fan 12V / car radiator fan 60*60*18
-
High Temperature 93*30mm DC24V Brushless Blower Vent Fan
-
Micro Equipment cooling systerm mini blower fan
-
Mirco Axial Cooling Fan 20*20*8mm /Super mini DC cooler fans
Product Details
| Electric Current Type | Other, DC AC | Mounting | Ceiling Fan | |
| Blade Material | Plastic | Place of Origin | Guangdong, China | |
| Brand Name | topfan | Model Number | YM2420AXB1 | |
| Voltage | 24V | Power | 36.00W | |
| Air Volume | 532.00CFM | Speed | 2500rpm | |
| Certification | CE, Other, UL, CE, ISO9000, UL, TUV, RoHS |
Product Description
Specifications
200 X 200 X 60mm axial cooling fan1. the newest cooling fan, hign speed and low noise
2. Ball Bearing made in Japan
Discription of 200 X 200 X 60mm axial cooling fan:
| Size(mm) | Model | Rated voltage (v) | Operating Voltage Range(v) | Current amp (Amp) | Rated Input Power Watt | Speed (rpm) | Max air Flow (CFM) | Max Static Pressure (Inch-H2o) | Noise Leve (dB-A) | Weight (g) |
| 200*200*60 | YM2420AXB2 | 24 | 14.0 to 27.6 | 1.5 | 36 | 2500 | 532 | 0.75 | 58 | 1031.4 |
1. Frame: Die-Cast Aluminum
2. Impeller: Plastic(UL94V-0)
3. Bearing type: Dual Ball Bearing
4. Leadwire: UL1007AWG#24 or Equipment (+): Red (-): Black
5. Motor: Impedence Protected and Reverse Polarity
1) Size: 200 X 200 X 60mm
2) Voltage: 24V
3) Dual Ball Bearing, higner static pressure, low noise
4) Certification: ISO9000, UL ,CE, RoHS, TUV
5) Expexted Life: 50,000 hours
6)widly used in the indutisl production equipment
Discription of our series 20060
| Size(mm) | Model | Rated voltage (v) | Operating Voltage Range(v) | Current amp (Amp) | Rated Input Power Watt | Speed (rpm) | Max air Flow (CFM) | Max Static Pressure (Inch-H2o) | Noise Leve (dB-A) | Weight (g) |
| 200*200*60 | YM2420AXB1 | 24 | 14.0 to 27.6 | 1.6 | 38.4 | 2800 | 595 | 0.82 | 65 | 1031.4 |
| YM2420AXB2 | 24 | 14.0 to 27.6 | 1.5 | 36 | 2500 | 532 | 0.75 | 58 | 1031.4 | |
| YM4820AXB1 | 48 | 28.0 to 56.0 | 0.9 | 43.2 | 2800 | 595 | 0.82 | 65 | 1031.4 | |
| YM4820AXB2 | 48 | 28.0 to 56.0 | 0.6 | 28.8 | 2500 | 532 | 0.75 | 58 | 1031.4 |
