Hot Recommend Double-column Hydraulic Press Machine
- Shanghai
- T/T Credit Card PayPal
You May Like
-
Good Quality Hydraulic Brick Press Machine
-
2014 Hydraulic c Frame Presses
-
MEILI-Y41-10T Single-column Small C-Frame Hydraulic Press Machine
-
MEILI-Y41-6.3T Single-column Hydraulic Press Machine for Correcting
-
MEILI-Y41-6.3T Single-column Hydraulic Blanking Press Machine
-
MEILI-Y41-10T Single-column Small Hydraulic Correcting Press Machine
Product Details
| Place of Origin | Jiangsu, China | Brand Name | MEILI | |
| Model Number | Y31 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Hot recommend double-column hydraulic press machine1.simple operation
2.two kinds of operations
3.various process uses
Hot recommend double-column hydraulic press machine
Type | Unit | 2.5T | 4T | 6.3T | 10T | 16T | 25T | 40T | |
Nominal force | KN | 25 | 40 | 63 | 100 | 160 | 250 | 400 | |
Max pressure of liquid | Mpa | 5 | 7.9 | 8 | 8.1 | 13 | 20.3 | 25 | |
Max opening height | MM | 300 | 390 | 450 | 500 | 550 | 600 | 600 | |
Ejector force | KN |
|
|
|
|
|
| 63 | |
Table size | F.B | MM | 400 | 400 | 400 | 400 | 450 | 450 | 450 |
L.R | MM | 400 | 400 | 400 | 400 | 400 | 400 | 400 | |
Ejector Stroke | MM |
|
|
|
|
|
| 120 | |
Slide speed | Idle stroke down | MM/S | 42 | 45 | 45 | 45 | 45 | 45 | 42 |
Working | MM/S | 0-42 | 0-45 | 0-45 | 0-45 | 0-45 | 0-45 | 10 | |
Return | MM/S | 77 | 77 | 81 | 81 | 80 | 80 | 70 | |
Outline dimensions | L.R | MM | 560 | 560 | 580 | 650 | 650 | 750 | 1484 |
F.B | MM | 725 | 780 | 935 | 1100 | 1140 | 1200 | 1350 | |
Height | MM | 1450 | 1630 | 1675 | 1800 | 1800 | 2100 | 2406 | |
Table height above the floor | MM | 700 | 710 | 700 | 710 | 710 | 710 | 700 | |
Diameter of blank-holding hole | MM | 70 | 70 | 80 | 80 | 100 | 100 | 100 | |
Motor power | KW | 2.2 | 2.2 | 3 | 4 | 5.5 | 5.5 | 5.5 | |
Total weight | T | 0.5 | 0.75 | 1 | 1.3 | 2 | 2.3 | 2
| |
Payment Terms:30% deposit in advance,70% payment before shipment.
Warranty: 1 year
1.Free installation, trial start and adjustment, training. But the machine quotation does not include the charges of our engineers in the buyer's country.
if you want, and the buyer must take charge of all the expenditure including tickets.
2. Warranty period is 1 year. During the warranty period we shall reply to the call or Fax from the user for the machine faults
(expect for faults caused by no abiding by the relevant operation regulations, or by for ce injury) within 24 hours.
Packaging:standard export packing or according to customers request.
If the buyer choose other ways for packaging,the extra fees will be for the buyer’s account.
Shipping:Generally,we are shipping by sea from Shanghai port.
If the buyer choose other port or other transport ways,the extra fees will be for the buyer’s account.
