Product Details
| Type | Condenser | Place of Origin | Shanghai, China | |
| Brand Name | Meluck | Model Number | FWS Series | |
| Certification | CE | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Shell and Tube Type water cooled Condensers
Product Descrption and Features
1. They are designed and produced strictly accorded with the National Standard and supervised under the National authority. We have specially manufacturing license for it.
2. The inner copper pipe is high efficient grooved type.
3. WS is suitable to air conditioning system; FWS is bigger vessel design, with liquid receivers.
4. The safety devices are equipped to assure safety for high temperature and pressure.
5. The product has been tested under the air pressure and water pressure, with 2.8MPa for shell and 1.0MPa for pipes.
6. The product has air evacuating devices, is convenient to evacuate unsolvable gas to improve the safety and efficiency of the products.
7. Super cooling pipes are employed to improve the efficiency.
8. Good quality welding makes it no debris and impurities left.
Design condition:
Temperature of cooling water in; T1 =30°C;
Temperature of cooling water out; T2 =35°C;
Condensing Temperature T=40°C,
Cooling water velocity: V=1.5-2m/s
Model | Capacity | Water Flow | Overall size (mm) | |||||
kW | m3/h | C | D | T | T1 | B | H | |
FWS-3 | 8.2 | 1.8 | 195 | 168 | 734 | 650 | 190 | 300 |
FWS-4 | 11.6 | 2.5 | 195 | 168 | 734 | 650 | 190 | 300 |
FWS-5 | 14.3 | 3.1 | 195 | 168 | 736 | 650 | 190 | 305 |
FWS-8 | 20.8 | 3.2 | 195 | 168 | 1076 | 990 | 190 | 305 |
FWS-10 | 28 | 6 | 238 | 219 | 1304 | 1200 | 250 | 350 |
FWS-15 | 43.5 | 9.4 | 238 | 219 | 1304 | 1200 | 250 | 357 |
FWS-20 | 57 | 12.3 | 300 | 273 | 1304 | 1200 | 300 | 410 |
FWS-25 | 69 | 15 | 300 | 273 | 1304 | 1200 | 300 | 410 |
FWS-30 | 80 | 17 | 300 | 273 | 1304 | 1200 | 300 | 410 |
FWS-35 | 99 | 21 | 300 | 273 | 1606 | 1500 | 300 | 410 |
FWS-40 | 115 | 25 | 300 | 273 | 1606 | 1500 | 300 | 410 |
FWS-45 | 126 | 27 | 300 | 273 | 1606 | 1500 | 300 | 410 |
FWS-50 | 142 | 31 | 300 | 273 | 2104 | 2000 | 300 | 410 |
FWS-55 | 157 | 34 | 300 | 273 | 2104 | 2000 | 300 | 410 |
FWS-60 | 177 | 38 | 300 | 273 | 2104 | 2000 | 300 | 410 |
