XJB Series Box Type Refrigeration Condensing Units
- Shanghai Ningbo
- T/T Money Gram
You May Like
-
1 LS Series Industrial Air Cooled Chiller Use for Vacuum Coating Machine Chiller Cold Room Compressor Refrigerator
-
3 LS Series Industrial Air Cooled Chiller Use for Vacuum Coating Machine Chiller Cold Room Compressor Refrigerator
-
2 LS Series Industrial Air Cooled Chiller Use for Vacuum Coating Machine Chiller Cold Room Compressor Refrigerator
-
3 Air Cooled Injection Molding Machine Chiller Cold Room Compressor Refrigerator
-
2 Air Cooled Injection Molding Machine Chiller Cold Room Compressor Refrigerator
-
1 Air Cooled Injection Molding Machine Chiller Cold Room Compressor Refrigerator
Product Details
| Condition | New | Temperature | 5~15°C,-5~5°C,-18~-35°C | |
| Place of Origin | Shanghai, China | Brand Name | Meluck | |
| Model Number | XJB | Voltage | 220V,380V,415V | |
| Dimension(L*W*H) | 1354x825x1235 | Weight | 100kg | |
| Certification | CE,ISO | Warranty | 1 year | |
| After-sales Service Provided | Overseas service center available |
Product Description
Fetures of these serie products:
1. Electric components were added on the basis of old XJQ series,including condensing unit, main control board, cold room temp control board and operation board. Cold room temp control board and operation board are optional.
2.Main control board can start/stop compressor by system low voltage, be suitable for super market, milk container,water chiller etc. If all optional included, system can control compressor by temp., with function of temp. and defrosting adjustment. The complete set of control system can be used for cold room directly, no extra controller required.
3.With multi protections including phase protection, phase lack, over current, too constant start of compressor, discharge temp and system high/low temp.
4.With fan speed regulator, to adjust condensing fan according to condensing temp. With operation data display function, to check operation current of compressor, discharge temp. and condensing temp.
5.With system alart function. When fault effects, the system will make alarm beep sound to remind user.
6.The operation board can show temp., setting, defrosting control, operation system data checking and coldroom temp. alarm functions. It can be installed apart from condensing units for remote control.
Parts of model specification
Model | XJQ02MAGY-E | XJQ03MAGY-E | XJQ04MAGY-E | XJQ05MAGY-E | XJQ06MAGY-E | XJQ07MAGY-E | ||
Room temperature | -15℃ ~5 ℃ | |||||||
Power supply | 380V/3Ph/50 HZ | |||||||
Compressor model | ZB15KQE | ZB21KQE | ZB29KQE | ZB38KQE | ZB45KQE | ZB48KQE | ||
Condenser | Fan Qty | 1 | 1 | 1 | 2 | 2 | 2 | |
Fan Voltage(V) | 220 | 220 | 220 | 220 | 220 | 220 | ||
Fan Input(W) | 120 | 120 | 120 | 120×2 | 120×2 | 120×2 | ||
Capacity&input | Te -5℃ | Cap(W) | 3820 | 5740 | 7840 | 9720 | 11450 | 13270 |
Input (W) | 1760 | 2500 | 3320 | 4200 | 4790 | 5243 | ||
Te -10℃ | Cap(W) | 3070 | 4680 | 6370 | 7910 | 9310 | 11047 | |
Input (W) | 1820 | 2510 | 3350 | 4200 | 4810 | 5265 | ||
Te -15℃ | Cap(W) | 2430 | 3780 | 5120 | 6380 | 7510 | 9114 | |
Input (W) | 1880 | 2520 | 3370 | 4200 | 4820 | 5277 | ||
Te -20℃ | Cap(W) | 1860 | 3010 | 4070 | 5090 | 6000 | 7442 | |
Input (W) | 1930 | 2520 | 3390 | 4190 | 4810 | 5280 | ||
Te -25℃ | Cap(W) | 1370 | 2370 | 3200 | 4010 | 4730 | 5200 | |
Input (W) | 1980 | 2520 | 3390 | 4180 | 4790 | 5900 | ||
pipe | Gas dia(mm) | φ19 | φ19 | φ19 | φ19 | φ19 | φ19 | |
Liquid dia(mm) | φ10 | φ10 | φ12 | φ12 | φ12 | φ12 | ||
Overall sizes | L (mm) | 1020 | 1020 | 1020 | 1020 | 1020 | 1020 | |
W (mm) | 420 | 420 | 420 | 420 | 420 | 420 | ||
H (mm) | 840 | 840 | 840 | 1240 | 1240 | 1240 | ||
Instal sizes(A×B)(mm) |
| 580×380 | 580×380 | 580×380 | 580×380 | 580×380 | ||
Overall sizes | A | |||||||
Model | XJQ08MBGY-E | XJQ09MBGY-E | XJQ10MBGY-E | XJQ13MBGY-E | XJQ15MBGY-E | ||
Room temperature | -15℃ ~5 ℃ | ||||||
Power supply | 380V/3Ph/50 HZ | ||||||
Compressor model | ZB58KQE | ZB66KQE | ZB76KQE | ZB95KQE | ZB114KQE | ||
Condenser | Fan Qty | 1 | 1 | 1 | 2 | 2 | |
Fan Voltage(V) | 380 | 380 | 380 | 380 | 380 | ||
Fan Input(W) | 550 | 550 | 550 | 460×2 | 460×2 | ||
Capacity&input | Te -5℃ | Cap(W) | 15250 | 17150 | 20300 | 25000 | 29700 |
Input (W) | 6320 | 7090 | 8200 | 10500 | 12650 | ||
Te -10℃ | Cap(W) | 12350 | 14000 | 16600 | 20000 | 24000 | |
Input (W) | 6310 | 7080 | 8200 | 10500 | 12600 | ||
Te -15℃ | Cap(W) | 9750 | 11300 | 13350 | 16000 | 18900 | |
Input (W) | 6310 | 7060 | 8100 | 10500 | 12650 | ||
Te -20℃ | Cap(W) | 7420 | 8990 | 10550 | 12200 | 14300 | |
Input (W) | 6310 | 7030 | 8000 | 10600 | 12800 | ||
Te -25℃ | Cap(W) | 5250 | 7030 | 8110 | 9000 | 10300 | |
Input (W) | 6310 | 6950 | 7930 | 10750 | 13100 | ||
pipe | Gas dia(mm) | φ28 | φ28 | φ28 | φ28 | φ28 | |
Liquid dia(mm) | φ16 | φ16 | φ16 | φ16 | φ16 | ||
Overall sizes | L (mm) | 967 | 967 | 967 | 1354 | 1354 | |
W (mm) | 825 | 825 | 825 | 825 | 825 | ||
H (mm) | 1035 | 1035 | 1035 | 1025 | 1025 | ||
Instal sizes(A×B)(mm) |
| 570×785 | 570×785 | 900×785 | 900×785 | ||
Overall sizes | C | ||||||
Model | XJQ10LBGY-E | XJQ13LBGY-E | XJQ15LBGY-E | ||
Room temperature | -18℃ ~-35 ℃ | ||||
Power supply | 380V/3Ph/50 HZ | ||||
Compressor model | ZF34K4E | ZF41K4E | ZF49K4E | ||
Condenser | Fan Qty | 1 | 1 | 1 | |
Fan Voltage(V) | 220 | 220 | 220 | ||
Fan Input(W) | 600 | 600 | 600 | ||
Capacity&input | Te -25℃ | Cap(W) | 8750 | 10850 | 13100 |
Input (W) | 7060 | 8920 | 11550 | ||
Te -30℃ | Cap(W) | 6950 | 8640 | 10400 | |
Input (W) | 6700 | 8490 | 11050 | ||
Te -35℃ | Cap(W) | 5430 | 6740 | 8120 | |
Input (W) | 6310 | 8060 | 10550 | ||
Te -40℃ | Cap(W) | 4140 | 5090 | 6270 | |
Input (W) | 5910 | 7620 | 10000 | ||
pipe | Gas dia(mm) | φ28 | φ28 | φ28 | |
Liquid dia(mm) | φ16 | φ16 | φ16 | ||
Overall sizes | L (mm) | 967 | 967 | 967 | |
W (mm) | 825 | 825 | 825 | ||
H (mm) | 1035 | 1035 | 1035 | ||
Instal sizes(A×B)(mm) |
| 570×785 | 570×785 | ||
Overall sizes | C | ||||
