FLOOR-TYPE MILLING AND BORING MACHINE MODEL TK6916

Specifications

This series product has the function of boring holes, drilling holes, milling and cutting, five faces machining can be done when equipped with a high accuracy rotary working table, a right- angle milling head and so on. It’s widely used in the fields of metallurgical, energy sources, electric power, mine, engineering mechanism, and military engineering industry, ship-building. The spindle adopts high-accuracy rolling bearings to support. The X, Y, Z axis equipped with rolling lead screw transmission, compensation equipment of spindle box, heat balance protection system, and double gears framework which could eliminating clearance. This machine has a function of completely self-diagnosis, which operates convenient and agile. All kinds of special accessories such as angle milling heads, special milling heads, facing plates, can be equipped according to customers’ requests.

Main Parameters:

Model: HTK250 CNC Heavy Rotary Table

Worktable Dimension: 2500×3000mm

The Hight of Worktable: 1300mm

Max. Workpiece of Worktable: 2000mm/3000mm

The Linear Traveling of Rotary Table: 2.5~2000mm/min

Linear Travel Speed Range of Rotary Table: 0.001~0.55r/min

Rotary Speed Range of Rotary Table: Siemens 840D

CNC System: Siemens 840D

Total weight of Rotary Table: 25000kg

Overall Dimension: 5744×2810×1300mm
