2014 Boiling Mixer Granulator Dryer
- Shanghai China
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Type | Drum Drying Equipment | |
| Place of Origin | Jiangsu, China | Brand Name | Xinan | |
| Model Number | FL-B | Voltage | 380V(or according to your requirement) | |
| Power(W) | 2.2 4.5.5 11 15 22 30 37kw | Dimension(L*W*H) | 1200*1200*3000mm | |
| Weight | 1250kg,1560kg,1670kg,1910kg,2100kg | Certification | ISO9001 | |
| Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1.FL-B Series Boiling Mixer Granulator Dryer2.Model:FL-B
3.Usage:Dryer food,chemical and medicine
FL-B Series Boiling Mixer Granulator Dryer
Trade manager:cn1510689227
Main Application:
FL-B Series Boiling Mixer Granulator Dryer is used to mix powder,dry and granulate it and coat in the industry of pharmaceutical,foodstuff and chemical.
Main Application:
Granulating:Tablet,instant soluble medicine,granules for capsule.
Coating:Granules,pill’s protecting layer,slow release layer,thin-film,enteric coating.
Feature:It produces particles with powders so as to improve the fluidity and reduce flying dusts.
It produces particles with powders so as to improve the solubility of the granules.
Mixing Granulating Drying 3 processes complete in one machine.
It adopts anti-static filter,safe operation is guaranteed.
There are pressure releasing holes to guarantee operating security.
The machine is designed according to GMP standard and made of stainless steel.The advantages of it are no blind spot,loading and discharging material easily and quickly,easy cleaning.
Operating Principle:
Powder flows in a cycle shape in the material container(fluidized bed).It is pre-heated by clean air and adhesive solution spays into the powder with the clean air together.Powder particles coalesce into granules and get dry.It has the feature of micro holes on the ball-shaped porous particles.
Nowadays, Jiangyin Xinan Machinery Co.,ltd have customers both in China and abroad.Foreign customers such as Russian,East Europe,Middle East,South America,North America,East Asia,Southeast Asia, Africa,etc.
| Model | 5 type | 15 type | 30 type | |
| Capacity | Min Group(kg/time) | 4 | 10 | 20 |
| Max Group(kg/time) | 6 | 20 | 40 | |
| Raw material vessel volume(L) | 2.2 | 45 | 100 | |
| Draught fan power | Normal (kw) | 2.2 | 4 | 5.5 |
| Filter and cyclone separator | 3 | 5.5 | 7.5 | |
| Steam | Consumption(kg/h) | 23 | 42 | 70 |
| Pressure(Mpa) | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | |
| Electricity heating power(Selected by customer) | 7.0 | 12 | 4.5 | |
| Compressed air | Consumption(m3/min) | 0.3 | 0.3 | 0.4 |
| Pressure(Mpa) | 0.4-0.6 | |||
| Working temperature(°C) | Room temperature -120°C auto adjustment | Room temperature -120°C auto adjustment | Room temperature -120°C auto adjustment | |
| Water content of product(%) | Mini 0.5 | Mini 0.5 | Mini 0.5 | |
| Recycling ratio(%) | ≥99 | ≥99 | ≥99 | |
| Equipment noise(dB) | ≤70 | ≤70 | ≤70 | |
| Main frame height(mm) | 2100 | 2200 | 2300 | |
| 60 type | 120 type | 200 type | 300 type | 500 type |
| 40 | 80 | 160 | 250 | 350 |
| 80 | 160 | 250 | 350 | 550 |
| 220 | 420 | 670 | 1000 | 1600 |
| 11 | 15 | 22 | 30 | 37 |
| 15 | 18.5 | 30 | 37 | 45 |
| 141 | 211 | 282 | 366 | 450 |
| 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 |
| 21 | 30 | 47 | 70 | 110 |
| 0.6 | 0.8 | 0.9 | 1.5 | 2.0 |
| Room temperature -120°C auto adjustment | Room temperature -120°C auto adjustment | Room temperature -120°C auto adjustment | Room temperature -120°C auto adjustment | Room temperature -120°C auto adjustment |
| Mini 0.5 | Mini 0.5 | Mini 0.5 | Mini 0.5 | Mini 0.5 |
| ≥99 | ≥99 | ≥99 | ≥99 | ≥99 |
| ≤70 | ≤70 | ≤70 | ≤70 | ≤70 |
| 3000 | 3300 | 3800 | 4100 | 4500 |
