Surveillance Camera/high Speed Dome Camera 530TVL

Address

0~255

Pan range

360°Continue

Tilt range

0°~90° Flip

Manual speed Pan

0.05~240°/Sec

Manual speed Tilt

0.05~180°/Sec

Preset speed

240°/Sec

Preset accuracy

±0.50°

Preset

256

Remote firmware updating and setup

to update firmware by RS485, to set ID by RS485

CruiseTours

8 Programmable(Dwell time speed preset point)

Speed setup for cruise tour

Yes

PatternTours

4 Programmable

Auto Scan

1 Programmable  (355° scan )

Alarm

Optional, 8 inputs, 2 outputs

Temperature setup and display

Temperature alarm & display on screen

Time adjustment

to adjust Time by broadcasting

Date/Time setup and display

Date/time display on screen and modify

Timer Programming

timer action

Integrate multi-protocol

Pelco_D/P, PEARMAIN, Pelco C (optional)

Protocol Automatic identify

Pelco_D/P, PEARMAIN

Total working time recording

to record total working time and time exceed limit

Home position

Yes, preset, cruise tour, pattern tour, auto scan, etc. available

Password protection

Yes

Long-focus speed-limited

Yes

Broadcasting address

Yes

Intelligent power-off memory current setting and state

Yes

anti-surge and anti-Lightning protection

Yes

OSD menu operation

Yes

Supporting camera

Automatic identify(Sony,Hitachi, Sanyo, LG, CNB )

Camera menu operation

Yes

Camera character programming

20 character

Privacy masking

Yes

Ingress Protection IP66

Yes

Operating Temperature

–55℃~65℃

Humidity

0%~90% (Non condensing)

Heater operate

(-5)℃ on +5℃off

Power

24VAC±25%,1.5A--2A,60Hz/50Hz

Consumption

heater off 12W  heater on 37W

communication

RS485 (+/-) orManchester

Connection

BNC cable

Image sensor

 1/4-type Ex-view HAD CCD

Number of total pixels

 Approx. 440,000 pixels

Lens

36x optical zoom, f=3.4 mm(wide) to122.4 mm(tele), F1.6 to F4.5

Digital zoom

12x (432x with optical zoom)

Angle of view (H)

57.8° (wide end) to 1.7° (tele end)

Minimum working distance

320 mm (wide end) to1,500 mm(tele end)

Sync system

Internal / External (V-lock)

Minimum illumination

1/60 s mode: 1.4 lx (typical) (F1.6, 50 IRE). 1/4 s mode: 0.1 lx (typical) (F1.6, 50 IRE)

Horizontal Resolution

530TVL

S/N ratio

More than 50 dB

Electronic shutter

1/1 to 1/10,000 s, 22 steps

White balance

Auto, ATW, Indoor, Outdoor, One-push WB, Manual WB

Gain

Auto / Manual (-3 to 28 dB, 16 steps)

AE control

Auto, Manual, Priority mode (shutter priority & iris priority), Bright, EV compensation, Backlight compensation, Slow AE)

Wide dynamic range

 On / Off

Backlight compensation

On / Off

Privacy zone masking

 On/Off (8 masks per view/24 masks presets in the entire viewing range when integrated into a PTZ camera - 14 colors, mosaic)

Character generator

Mode display/Multi-line OSD (OSD has priority over Mode display)

Focusing system

Auto (Sensitivity: normal, low), One-push AF, Manual, Infinity, Interval AF, Zoom Trigger AF

Picture effects

 E-Flip, Nega Art, Black & White, Mirror Image

Camera operation switch

Zoom tele, Zoom wide

Video output

 VBS: 1.0 Vp-p (sync negative), Y/C

Camera control interface

 VISCA (TTL signal level), baud rate: 9.6 Kb/s, 19.2 Kb/s, 38.4 Kb/s, 1 or 2 Stop bit selectable

Storage temperature

(-)20 to60 °C(-4 to140 °F)

Operating temperature

 0 to50 °C(32 to122 °F)

Power consumption

 6 to 12 V DC/2.6 W (motors inactive),4.9 W (motors active) Mass230 g(8.1 oz)

Dimensions

Dimensions (W x H x D) 50.0 x 57.5 x87.9 mm(2 x 2 3/8x 3 1/2inches)
