Home > Products > DC Generator > Kohler Diesel 48V 100A DC Genset
Kohler Diesel 48V 100A DC Genset
USD $4,100 - $5,900
/ Set
1 Set(Min. Order)
- Chongqing
- T/T
You May Like
Product Details
| Place of Origin | Chongqing, China | Brand Name | YOHOU | |
| Model Number | YH60000MC48-100 | Output Type | DC | |
| Speed | 3600 | Frequency | 60HZ | |
| Rated Power | 6KVA | Rated Voltage | 48V | |
| Rated Current | 100A |
Product Description
48V 10KVA/8KW DC Genset
Description
Power Rang: 6kw
Voltage: 48V
Current: 100A
Alternator: 48V DC PMA /PERMANENT MAGNET GENERATOR ALTERNATOR
Engine: KOHLER
Application: 48V 6KW DC Genset for Telecom
Technical Parameter
| Model | YH60000MC48-100 | |
| Generator alternator | DC Output Voltage | 48V (40V-59Vcontinuous adjustable) |
| or | 24V (20V-30Vcontinuous adjustable) | |
| DC output Curret | 100A | |
| DC Output Power | 6KW/3600RPM | |
| Engine | Brand | KOHLER KD500 |
| Type | Single cylinder, air cooled, 4 strokes | |
| Displacement (CC) | 505CC | |
| Continuous Rated Power | 6KW/3600RPM | |
| Start Type | Electric start | |
| Lubricate Oil Type | SAE20 (10-20℃ Spring/Autum) | |
| Lubricate Oil Capacity | 1.L | |
| Fuel Type | Diesel 0# (Summer)/-20# (Winter) | |
| Fuel Consumption(g/kw.hr) | ≤191 | |
| Environment | Atmospheric pressure | 70kPa~106kPa |
| Work Temperature | -20℃~+60℃ | |
| Storage Temperature | -40℃~+70℃ | |
| Protection | Protection Functions | battery reverse connection protection, |
| timing shutdown protection, | ||
| grid supply auto-shutdown protection | ||
| engine preheating protection; | ||
| engine lubricating oil level alarm protection, | ||
| over-voltage protection, | ||
| over-current protection, | ||
| limit-current protection, | ||
| short-circuit protection, | ||
| module over-heating protection | ||
| Start Conditions | Stationary AUTO Type | Grid Power Unavailable |
| Stationary AUTO Type | Lower than 48V Batteries Lower Limit Voltage | |
| Shutdown Condition | Stationary AUTO Type | Grid Power available |
| Stationary AUTO Type | batteries voltage value higher than upper limit voltage value, batteries charging current, Timing shutdown | |
| Fuel Tank Capacity (L) | 25L | |
| Gneset | Continuous work time | 24 Hours |
| Noise level [non-load~full-load[dB(A)/7M] | 82~90 | |
| Dimensions(L×W×H) (mm) | 810×700×720 | |
| Weight(net weight)KGS | ≤100kg |
