TCG GR Orthogonal Gear Motor
- Fob Shenzhen or Hongkong
- Credit Card
You May Like
-
Micro Motor, AC , From 6w--200w, High Torque, Low Noise
-
90W 90MM Frame Induction Motor With Gearhead 110/220v 1300rpm
-
Stepless Variable Speed Control Induction Gear Reducer Motors
-
TCG Electrical Continuous Variable Speed Controller Motor
-
AC Gear Induction Motor 110v/220v
-
Induction AC Electrical Motor With Gear Box
Product Details
| Input Speed | 1500rpm | Output Speed | 0-1500 | |
| Place of Origin | Guangdong, China | Model Number | GR | |
| Brand Name | TCG |
Product Description
TCG GR orthogonal gear motor
1 TCG gear motor characteristics
Small size ,flexible installation
High efficiency , high torqu , steady and long life
With motor: AC/DC , standardized/special
Optional parts:speed controller,fan,braker etc
Ratio:1:5-1:750 MAX with middle reducer
Power:25-2000W they apply to trismission of auto-and semi-auto-q
equipemnts as food medicine and advertising etc
2 TCG gear motor technicial issue
2.1 Generail technical condition
insulation resistance:>20M
Insulation strenght: 1500v/1min no brekdonw or flashover
limit of tem rise: 75k
wire for motor: CQC 105C 600V
2.2Basic work consition
Work siystem: Continuous
Way of cooling IC 40
2.3 Basic environment condition
temperature:-10C +40C
relative humidity:15% to 90%
