Home > Products > HD IP Cameras & NVR > Economic 9CH 720P/960P/ 1080P P2P Onvif NVR POE NVR
Economic 9CH 720P/960P/ 1080P P2P Onvif NVR POE NVR
USD $38 - $56
/ Set
1 Set(Min.Order)
- 1000000 Set / Sets per Month
- shenzhen
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Guangdong, China | Model Number | EK-NV8101SL | |
| Style | Other |
Product Description
Specifications
9CH nvr with , WITH HDMI, 2USB, VGA, Support 4channel 720P/960P/1080P
Main Features:
Friendly operation system
Specifications:
| System | ||
| Main processor | High performance embedded microprocessor-20A | |
| Operating system | Embedded LINUX OS | |
| Video spec. | ||
| Video compression format | H.264 | |
| Display Image Resolution | D1@30fps;720P@30fps;960P@30fps;1080P@30fps | |
| Playback Image Resolution | 720P@30fps;960P@30fps;1080P@30fps | |
| Motion Detection | can setup 192(16×12)pcs motion detection area each channeland multi-level sensitivity(1-6 levels adjustable) | |
| Privacy Masking | Depends on ipc | |
| Audio spec. | ||
| Audio compression format | adpcm | |
| Two-way audio | 1ch | |
| Recording | ||
| Recording Mode | Manual Recording, Motion Detection Recording, Time Recording, Alarm Recording, | |
| Recording storage | HDD,Network | |
| Frame rate | 30 fps NTSC;25fps PAL | |
| Recording Playback | Max suport 4ch 960P or 2ch 1080P synchronously playback | |
| Backup Mode | Support HDD,USB Flash Disk store & backup | |
| Video | Network Video Input | 1ch |
| Video output | 1ch VGA and 1ch HDMI | |
| Audio | Audio Input | 9ch IPC Composite Audio |
| Audio Output | 1ch(support two-way audio) | |
| Alarm | Alarm Input | 4ch Alarm Input |
| Alarm Output | 1ch Alarm Output | |
| Other | Network | 1x10/100Mbps,RJ45 port |
| RS485 | Standard 485 port,support half-duplex, green terminal port | |
| USB | 2 USB 2.0 ports | |
| HDD | support 1pcs 2TB SATA HDD inside | |
| Power | DC +12V /4A | |
| Power consumption | 16W-18W(not include HDD and PoE) | |
| Operation temperature | 0°C-+55°C | |
| Operation humidity | 10%-90% | |
| Demension | 252*213*42mm(0.8u hight) | |
| Weight | 1.5--1.8KG(not include HDD) |
