Home > Products > Printing Machine > Two Color Printing Machine (YT Series)
Two Color Printing Machine (YT Series)
- Shanghai / Ningbo
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Plate Type | Other, flexo printing machine | |
| Place of Origin | Zhejiang, China | Brand Name | MTED | |
| Model Number | Y-21600, YT-21800, YT-21000, YT-21200, YT-21400 | Usage | Paper Printer, Tube Printer | |
| Automatic Grade | Automatic | Voltage | 380V | |
| Gross Power | 13kw | Dimensions(L*W*H) | 2300*2500*2200mm | |
| Weight | 2400kg | Certification | CE | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1.Easy operation2.flexible starting
3.accurate colour register
4.Two color printing machine
YT TWO COLOR PRINTING MACHINE
Use
Suitable for printing such packing materials as non-woven fabric,polyethylene, polypropylene plastic bag, glass paper,etc. It is a kind of ideal printing equipment for producing paper package, supermarket handbag, vest bag and clothes bag, etc.
Function:
1 Easy operation, flexible starting, accurate color register.
2 The meter counter an set printing quantity according to the requirement,Stop the machine automatically at the quantity,Stop when the material is cut off.
3 Lift and lower the printing plate cylinder manually,it will automatically stir the printing ink automatically after lifting.
4 The printing ink is spread by the anilox cylinder with even ink color.
5 Reliable drying system coordinated with high speed rotation, it will automatically break circuit when the machine stops.
6 360°continuous and adjustable longitudinal register device.
7 The import frequency controller of motor speed adapts to different printing speed.
8 there are inching/stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.
Main Technical Parameters:
Model | YT-2600 | YT-2800 | YT-21000 | YT-21200 | YT-21400 |
Max.Width of Printing Material (mm) | 600 | 800 | 1000 | 1200 | 1400 |
Max.printing Width(mm) | 560 | 760 | 960 | 1160 | 1360 |
Length Range of Printing Product(mm) | 191-914 | 191-914 | 191-914 | 191-914 | 191-914 |
Max.Diameter of Roll Material(mm) | 450/1000 | 450/1000 | 450/1000 | 450/1000 | 450/1000 |
Printing Speed (m/min) | 5-50 | 5-50 | 5-50 | 5-50 | 5-50 |
Thickness of plate(mm) (including Two-sided Glue Paper) | 2.38/3.94 | 2.38/3.94 | 2.38/3.94 | 2.38/3.94 | 2.38/3.94 |
Power Supply(V) | 380V (three-phase four-wire power cable) | 380V (three-phase four-wire power cable) | 380V (three-phase four-wire power cable) | 380V (three-phase four-wire power cable) | 380V (three-phase four-wire power cable) |
Total Power(kw) | 8kw | 10kw | 11kw | 11kw | 13kw |
Machine Weight(kg) | 1800kg | 1900kg | 2100kg | 2300kg | 2400kg |
Incasement Weight(kg) | 2000 | 2100 | 2300 | 2500 | 2600 |
Machine Dimensions (mm) | 2300x1700 x2200 | 2300x1900 x2200 | 2300x2100 x2200 | 2300x2300 x2200 | 2300x2500 x2200 |
