Li-ion/li Polymer 10S 20A BMS/PCM/PCB

FOB Price

Negotiable / Piece

10 Pieces(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	China		Brand Name	OSN Power
Model Number	OSN-10S2005-BMS

10S 20A BMS for Li-ion/ Lipo 37V battery pack
Continuous/Peak Discharge Current:20A/40A
Charge Current: 5A

BMS Specifications For 10S Li-ion Battery Packs
Model: OSN-10S2005-BMS
No.	Test item		Criterion
1	Voltage	Charging voltage	DC:42V CC/CV
1	Voltage	Balance voltage for single cell	4.20+0.025V
2	Current	Balance current for single cell	84+10mA
		Current consumption for single cell	≤20μA
		Maximal continuous Charging current	5A
		Maximal continuous Discharging current	20A
3	Over charge Protection	Over charge detection voltage	4.25+0.025V
		Over charge detection delay time	0.5—2S
		Over charge release voltage	4.25+0.05V
4	Over discharge protection	Over discharge detection voltage	2.50+0.062V
		Over discharge detection delay time	10-300mS
		Over discharge release voltage	2.5+0.062V
5	Over current protection	Over current detection voltage	0.62V
		Over current detection current	90+10A
		Detection delay time	5ms—20ms
		Release condition	Cut load, Automatic Recovery
6	Short protection	Detection condition	Exterior short circuit
		Detection delay time	200-500us
		Release condition	Cut load, Automatic Recovery
7	Resistance	Protection circuitry (MOSFET)	≤20mΩ
8	Temperature	Operating Temperature Range	-40~+70°C
8	Temperature	Storage Temperature Range	-40~+125°C
9	Weight		0.085kg
10	Size		L65W50T14mm
