Trade Assurance750 Cold Steel Structural Floor Decks Machine
- TIANJIN PORT
- T/T
You May Like
-
Trade Assurance High Quality XH555 Floor Decking Sheet Roll Forming Machine
-
BOTOU 555 Floor Deck Tile Roll Forming Machine China Manufacturer
-
Trade Assurance 555 Garage Metal Floor Decking Roll Forming Machine
-
555 Metal Sheet Floor Deck Roll Former
-
XH1025 Sheet Floor Deck Machine
-
XH1025 Floor Deck Cold Roll Forming Machine
Product Details
| Condition | New | Type | Tile Forming Machine | |
| Tile Type | Colored | Use | Wall | |
| Production Capacity | 6-8m/min | Place of Origin | Hebei, China | |
| Brand Name | XINGHE | Model Number | 750 | |
| Power(W) | 18.5kw | Voltage | 380V 50Hz 3phases | |
| Dimension(L*W*H) | 18000*1000*1200 | Weight | 14T | |
| Certification | BV CE | Warranty | 12 Months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
XH750 roof panel cold roll forming machine
1. the chart of process flow
Decoiling—active feeding (put the coil strip into the first feeding roller)—leveling —roll forming —computer control system—hydraulic cutting—product to stand
2. Technical specifications
Main forming machine
machine size | 6000mm*1300mm*1200mm |
Feeding width | 1000mm |
Equipment weight | 2.5T |
Material of shaft | 45#steel adjustable treatment |
Out diameter of shaft | φ70mm |
Material of roller | Cr12, quenched treatment HRC58-60°C |
Forming rollers | 14rows |
Main frame | 300 H steel |
Thickness of medium plate | 12mm |
Transportation system | Chain transportation |
Thickness of chain | 0.6 inch |
Main motor power | 3 KW |
Bearing | 6213 |
Gear box | 150*150 |
Forming speed | 8000-10000mm/min |
Rolling thickness | 0.3-0.8mm |
Hydraulic shearing
Material of blade | Cr12,heat treatment 60-62°C |
Shearing system | It is controlled by gear wheel oil pump. After filling the hydraulic oil into the hydraulic oil tank, the pumps drive the cutter machine to begin the cutting job. The system includes a set of hydraulic tank, a set of hydraulic oil pump, two hydraulic pipes. And two sets of electromagnetism valves. Power of the oil pump: 4kw Hydraulic oil :40# |
Electrical system
Screen display | 5.7 inches touch screen |
Main computer control cabinet | It adopts industrial computer to control. The target piece’s length is adjustable and digit of it can be adjusted. Computed mode has two modes: automatic and manual one. The system is easy to operate and use. Processing precision : within 1.00mm It contains liquid crystal screen, programmer, transformer for the electronic machines and kits of every part. Transducer brand is EURA The seller should provide Chinese and English language screen. |

Package & Payment & Delivery | ||
1 | Package details | Nude fasten up in container or under your requests |
2 | Payment terms | 30% TT for deposit balance against copy of B/L 100% L/C at sight |
3 | Delivery time | Within 30 days after receipt deposit |
4 | Port of shipment | XINGANG TIANJIN |
Our Service | |
1 | One-year quality assurance for all the machine |
2 | Technical staff available to service machine overseas |
3 | Permanent free for technical support |
4 | Design and produce according to your sample or drawing |
Machine Feature:
1.Precise forming
2. High-solid forming stand guarantees the goods and uniform high quality of final produced
3. The operation automatically minimizes the tolerance of cutting length
4.Machine with Draw knife that can make the last board without manual cutting and clutch,That can control the number plate.
1. Does one machine can only produce one style panel profile?
Not exactly.For wider and double layer making machine. It can produce more than 6 kinds of panels.
2. Do you have after sales support?
Yes, we are happy to give advice and we also have skilled technicians available across the world.We need
your machines running in order to keep your business running.
3. How to visit your company?
a.Fly to Beijing airport: By high speed train From Beijing Nan to CangZhou Xi (1 hour), then we can pick
up you.
b.Fly to Shanghai Airport: By high speed train From Shanghai HongQiao to Cangzhou Xi(4.5 hours), then
we can pick up you.
4. What can you do if the machine broken?
Our machine's warranty period is 12months,if the broken parts can't repair,we can send the new parts replace the broken parts freely,but you need pay the express cost yourself.if after warranty period,we can
through negotiation for to solve the problems,and we supply the technical support for the whole life of the
equipment.
5. Can you be responsible for transport?
Yes,please tell me the destination port or address.we have rich experience in transport.
6. You are trade company or factory?
We are trade company but we also have own factories. Building trade company is just for exporting
various types of cold roll forming machines.
7. Why your price is higher than others?
As we persist on that each factory should put quality at the first place. We spend time and money on
developing how to make machines much more automatic, accurate and high quality. We can make sure
