200L Gravity Solar Water Heaters

FOB Price

US$ 80 - 500 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China	Brand Name	Inlight or OEM
Type	Non-Pressure	Application	Water Heater
Pipe Material	Other, Borosilicate glass 3.3 (Linuo)

We supply different capacity home use solar water heaters,
Reliable quality,Stainless steel inner produce drinkable hot water

Haining Yinuo electric Co., Ltd manufactures and supplies all kinds of solar water heaters, solar collectors.

Our professional group will design the best solar heating system solutions for your domestic house, hotel, hospital or industry plants.

Gravity Solar Water Heaters

Specification:
1. Solar Water Heater Storage Tank Capacity: 80L,100L,120L,150L,200L,250L,300L,400L,500L
2. Heat Collecting Type: Glass evacuated tube solar collector
3. Inner Storage Tank Material: Food-grade stainless steel SUS304-2B or SUS316 0.4mm,0.5mm,0.6mm
4. Tank Exterior Shell Material: High-quality white coated color steel or stainless steel 0.4MM
5. Heat Insulation: High-density polyurethane foam layer with 72~80 hours heat preservation
6. Thickness of Insulation Layer: 50mm, 55mm, 60mm, 70mm
7. Vacuum Tube Model: Φ47/1500mm, Φ47/1800mm, Φ58/1800mm
8. Vacuum Tube Material: Borosilicate glass 3.3
9. Vacuum Tube Absorbing Coating: AL/AL-ALN or Cu-SS-ALN/AIN
10. Bracket: Hot-dip galvanized steel,stainless steel or aluminum alloy
11. Angle of bracket: 10°-50°, universal bracket suitable for slope and flat roof installation
12. Accessories: Stainless bolts & nuts, anti-aging silicon gasket, dustproof rubber seal, air-vent cap
13. Angle of bracket: 20°-50°
14. Hot Water Output:45-95°C
15. Designed Pressure:0.5 Bar
16. Optional components: Controller, Electric heater, Anode magnesium bar, Assistant tank
