Non-pressurized All Glass Tube Color Steel Solar Water Heater
- SHANGHAI/NINGBO
- T/T Credit Card
You May Like
-
Non Pressure Color Steel Direct Plug Solar Water Heater
-
Non Pressure Color Steel Batch Solar Water Heater
-
Non Pressure Color Steel Direct Solar Water Heater Quality Choice
-
Silver PVDF Plate Non-Pressurized Solar Water Heater
-
Integrated Non Pressure Stainless Steel Solar Hot Water Heater
-
Color Steel Integrated Non-pressurized Solar Hot Water Heating
Product Details
| Type | Evacuated Tube | Pressure | Unpressurized | |
| Circulation Type | Direct / Open Loop (Active) | Heating System | Thermosyphon (Passive) | |
| Connection Type | Direct-Plug | Installation | Freestanding | |
| Housing Material | Other, Fluorocarbon plate (PVDF) | Certification | CE, Other, CE, CCC ISO9001:2008 | |
| Capacity | 300 | Place of Origin | China | |
| Brand Name | INLIGHT | Model Number | ILN-V0323 |
Product Description
Specifications
1.OEM available2.Easy installation, convenient operation
3.Assured quality, fast delivery
Non-pressurized all glass tube color steel solar water heater
Product Description
| Vacuum tube | Spec. (mm) | Φ 47× 1500 Φ 58× 1800 Φ 70× 2000 |
| Tube (pcs) | 15 / 16 / 18 / 20 / 24 / 30 / 36 | |
| Material | Borosilicate glass, magnetron sputtering selective coating | |
| Coating | AL/AL-ALN(H)/AL-ALN(L)/ALN | |
| Water tank | Capacity | 100 ~ 400L for inner water tank |
| Inner tank | Food-grade stainless steel SUS304-2B 0.4MM | |
| Insulation | Imported polyurethane integrated foam-forming 50~60mm | |
| Tank shell | High-quality silver fluorocarbon (PVDF) plate 0.4 mm | |
| Bracket | Spec. (mm) | 1.2 ~ 1.5mm in thickness |
| Material | Hot-dip galvanized steel plate | |
| Accessories | Stainless bolts & nuts, Silicon rubber seal, Dustproof rubber seal, Plastic pipe holder | |
| Optional device | Electrical heater, Intelligent controller / Assistant tank, Anod magnesium bar | |
| Tilt angle | 25° ~ 50° | |
| Water output | 45-95 centigrade | |
| Hail resistance | 25mm | |
Features description:
Non-pressurized solar water heater works depending on the gravity of water, so it's much better to be installed on the slope or flat roof as high as possible to get enough hydraulic pressure. A simple assistant tank can be equipped for tap water refill automatically or with an intelligent controller to control the startup of auxiliary heating device at the same time.
Vacuum tube: Hail-resisting borosilicate glass with high-tech selective coating ensures an efficient solar collecting.
Inner water tank: Food-grade stainless steel SUS304-2B as inner tank keeps the water clean and drinkable, together with advanced welding technics to ensure it with a long lifespan (15 years).
Water tank shell: Imported color steel plate, with its outer coating treatment ensures a long life even to ocean coast weather.
Insulation Layer: Germany-imported polyurethane integrated foam-forming with twice slaking treatment, preserve hot water constantly as long as 70~80 hours.
Supporting Bracket: Hot-Dip galvanized steel plate with a good weight bearing and wind resistance(140 km/hr), super mechanical performance and corrosion resistance ensures a long life to ocean coast, easy installation, universal bracket suitable for either flat or slope roof installation.
Accessories: Stainless bolts & nuts, water-proof silicon rubber, anti-aging dustproof rubber seal, plastic pipe holder and ventilating cap to ensure their lives as long as other parts of the system
Optional Devices
Assistant tank: to automatically feed tap water into storage tank to keep it sufficient always
Electrical heater:as an auxiliary heating element in case of raining or snowing days so as to ensure a continous hot water supply
Intelligent controller: automatically controls water refill and startup of auxiliary heating device, more intelligent operation
Booster Pump, a choice for those area without tap water or with a unstable water supply
Warranty:
3 years international responsibility for integrated system and 15 years for glass vacuum tubes due to original quality problems
