42inch Multitouch Touch Monitor

FOB Price

US$ 600 - 900 / Unit

1 Unit(Min. Order)

Port Beijing
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Products Status	Stock	Screen Size	Other, 42inch
Type	Infrared	Interface Type	D-Sub, DVI, Serial, USB
Resolution	Other, 1920X1080	Brand Name	LeadingTouch
Model Number	TM-4258	Place of Origin	Beijing, China

Product Description

Specifications

1, 42inch Multitouch touch monitor
2, Infrared touch technology
3, USB
4, VGA,DVI and HDMI
5, resolution 1920 x 1080

TM-4258 Multitouch Infrared Touch Screen LCD touchmonitor with a removeble stable tilt base and IP65 Infrared touch screens. These LCD monitors provide you with premium quality in optical resolution, durability and stability. Built with high quality ABS plastic frame along with unique designed and integrated watertight IP65 rated plastic bezel, this unit becomes completely dust and water proof. This is an ideal solution for harsh environments that are humid, dust and water proof. These could also withstand various public and weather conditions.

Model	TM-4258
Description	42" Open Frame Infrared(IR) Touch Monitor
Case/Bezel Color	Black
Display	16:9 Active Matrix TFT LCD
Optimal (native) Resolution	1920 × 1080@60Hz
Sychronization Range	Horizontal: 60 - 73 KHz, Vertical: 47 - 63 Hz
Useful Screen Area	934 x 527mm
Colors	16.7 M
Brightness	350 cd/m2
Pixel Pitch	0.4845 × 0.4845mm
Response Time	6.5ms (Typically)
Contrast Ratio	3000:1 (Typical)
Viewing Angle(CR≥10)	Horizontal: ±89° or 178° total
Viewing Angle(CR≥10)	Vertical: ±89° or 178° total
Backlight Lamp Life	50000 hrs
Input Video Format	VGA / DVI / HDMI
Input Video Signal Connector	VGA/ DVI / HDMI
On Screen Display(OSD)	Controls (back): ON/OFF,MENU,LEFT,RIGHT,SEL,AUTO
Touch Technology	Leadingtouch Infrared(IR),Single-Touch or Dual-Touch
Touch Interface	RS232 or USB or Dual RS232&USB interface
Mounting Options	VESA Mount (200mm × 400mm) , Side Mount or Front Mount with optional bracket
Power Supply	100-240VAC, 50-60Hz
Power Consumption	157W Max
Temperature Range	Operating: 0°C to 50°C; Storage: -20°C to 60°C
Humidity Range (no condensing)	Operating: 20%-80%; Storage: 10%-90%
Dimension	Touchmonitor 1007 x 600 x 122.5mm, net weight 31.4kg
Dimension	Box after packing : 1130 x 310 x 850mm weight 37.6kg
Warranty	1 year
Agency Approvals	FCC, CE, RoHS
