HQJ-A4 A4 Paper Cutting Machine
- NINGBO
- T/T Credit Card PayPal
You May Like
Product Details
| Condition | New | Type | Paper Cutting Machine | |
| Computerized | Yes | Place of Origin | Zhejiang, China | |
| Brand Name | RUIHAI | Model Number | HQJ-A4 | |
| Voltage | 380V 50Hz | Power(W) | 9.5KW | |
| Dimension(L*W*H) | 12000*1900*2000mm | Weight | 3500KG | |
| Certification | CE Certificate | Warranty | One Year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Performance and Characteristics
This A4 paper cutting machine is suitable for cutting big rolling packaging materials , such as office, paper-plastic, photo paper material, etc.
1. It adopts PLC touch screen control, servo motor for controlling constant-length cutting.
2. It adopts pneumatic, photoelectric sensor for controlling transmission system, with photoelectric, gas together, it has functions of easy operation, high precision, good stability and low noise.
3. This A4 paper cutting machine has the functions of the frequency converter timing device, automatic counting, stop working by alarm magnetic powder tension control, can be cut vertically, adopt blower to get rid of waste.
4. This machine can be with 1 roll, 2 roll and 4 roll loading system.
5. This machine can connected with the packaging machine directly.
Main Technical Parameters
| Model | HQJ-1100A4 | HQJ-1400A4 |
| Max. width of cutting | 1100mm | 1400mm |
| Max. diameter of material | Φ1400mm | Φ1400mm |
| Min. width of cutting | 50mm | 50mm |
| Length of cutting | 20-400mm | 20-400mm |
| Speed | 10-140times/min | 10-140times/min |
| Precision | ±0.2mm | ±0.2mm |
| Total Power | 9.5KW | 11KW |
| Weight | 3500kg | 4000kg |
| Overall dimension(L*W*H) | 12000*1900*2000mm | 12000*2200*2000mm |
Detailed photos
whole view
2 rolls
automatic stack and never interlace
FEEDBACK(if u need more information or videos, pls do not hesitate to contact with me)
