Home > Products > Cutting machine series (Roll to sheet) > A4 Cross Cutter
A4 Cross Cutter
- ANY PORT IN CHINA
- T/T
You May Like
Product Details
| Type | Paper Cutting Machine | Computerized | Yes | |
| Place of Origin | Zhejiang, China | Brand Name | RUIHAI | |
| Model Number | HQJ-D(A4) |
Product Description
Specifications
A4 cross cutter-Specalist for A4 A3 and A1 etc
-PLC control
-can be 1 ,2, 4 roll
Performance and Characteristics
This A4 cross cutter A4 sheet cutting machine ( A4 paper sheeter )is suitable for cutting big rolling packaging materials such as paper,paper-plastic,multicolor laminated material,etc.
1.A4 cross cutter adopts PLC touch screen control, servo motorfor controlling constant-length cutting.
2. A4 cross cutter adopts pneumatic,photoelectric sensor for controlling transminssion system,with photo,electric,gas together,it has the functions of easy operation,high precision,good stability,low noise
3. A4 cross cutter has the functions of the frequency converter timing device,auto-matic counting,stop working by alarm magnetic powder tension control,can be cutted vertically,adopt blower to get rid of waste.
| Model | HQJ-1100D(2 or 4 roll) | HQJ-1400D(2.4roll) |
Max.width of cutting | 1000mm | 1300mm |
Max diameter of material | Φ1400mm | Φ1400mm |
Min.width of cutting | 50mm | 50mm |
Length of cutting | 20-400mm | 20-400mm |
Speed | 10-140times/min | 10-140times/min |
Precision | ±0.2mm | ±0.2mm |
Total Power | 9.5kw | 11kw |
Weight | 3500kg | 4000kg |
Overall dimension(LXWXH) | 8600x1500x2000mm | 8600x1800x2000mm |
A4 paper sheeter cutting machine with 1 rolls:
A4 paper sheeter cutting machine with 2 rolls
Unwinding stand of A4 sheeter cutting machine :
Cutting parts of This A4 paper shetter
Back side of This A4 paper sheeter:
If need more details or vedio of the A4 paper sheeter cutting machine please be free to contact with us
