Final manufacture in China for A4 cutting machine

Condition	New		Type	Paper Cutting Machine
Computerized	Yes		Place of Origin	Zhejiang, China
Brand Name	RUIHAI		Model Number	HQJ-D(A4)
Voltage	380V or 220V (as customer request)		Power(W)	7-15kw (different model has different power)
Dimension(L*W*H)	L:8600MMXW:1500MMXh:2000MM		Weight	3000kg-5000kg
Certification	CE.SGS		Warranty	1 year
After-sales Service Provided	Engineers available to service machinery overseas

Specifications

A4 paper cutting machine
-Specalist for A4 size A3 size and A1 size etc
-PLC control,fully automtic
-can be 1 ,2, 4 roll

Comments:

We are the final manufacture of this kind of A4 paper cutting machine in China

Performance and Characteristics



This A4 paper cutting machine ( A4  paper sheeter )is suitable for cutting big rolling packaging materials such as paper,paper-plastic,multicolor laminated material,etc.



1. It adopts PLC touch screen control, servo motorfor controlling constant-length cutting.



2.it with slitting knives to slitting then cut to have different sizes of paper like a4,a3,a2,a1 or any other sizes .width and length can be both adjustabl

2. It adopts pneumatic,photoelectric sensor for controlling transminssion system,with photo,electric,gas together,it has the functions of easy operation,high precision,good stability,low noise

3. This machine has the functions of the frequency converter timing device,auto-matic counting,stop working by alarm magnetic powder tension control,can be cutted vertically,adopt blower to get rid of waste.



Model	HQJ-1100D(1 or 2 or 4 roll)	HQJ-1400D(1or2 or 4roll)
Max.width of cutting	1100mm	1400mm
Max diameter of material	Φ1400mm	Φ1400mm
Min.width of cutting	50mm	50mm
Length of cutting	20-400mm	20-400mm
Speed	10-140times/min	10-140times/min
Precision	±0.2mm	±0.2mm
Total Power	9.5kw	11kw
Weight	3500kg	4000kg
Overall dimension(LXWXH)	8600x1500x2000mm	8600x1800x2000mm













































The Machine with 1 paper roll:

The Machine with 2 paper roll:



Unwinding stand:

Cutting parts:

Back side:



Engineer testing the machine in good working condition before shippment



Packing in strong wooden cases for export and Loading in the container







CE Certified Ruihai Machinery Company Brand as the final manufacture



If need more details or vedio of the machine please be free to contact with us
