China First Class Cnc Acrylic Board Polishing Machine
- Qingdao port is the most convenient Shanghai Tianjin Guangzhou and other port is also available.
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
China Best CNC Acrylic Sheet Polishing Machinery
-
CNC Acrylic Surface Grinding Machine and Acrylic Polishing Machine
-
Automatic Acrylic Polishing Machine Manufacturer
-
New Product Adjustable Angle Acrylic Edge Horizontal Long Axis Polishing Machine
-
China Top Quality Adjustable Angle Horizontal Organic Glass Edge Cutting and Polishing Machine
-
China Top Quality Adjustable Angle Horizontal Acrylic Sheet Edge Cutting and Polishing Machine
Product Details
| Place of Origin | Shandong, China | Brand Name | DEMACS OR OEM | |
| Model Number | DMS-1300W | Type | Other, Acrylic Polisher | |
| No-Load Speed | 6000-9000r/min | Rated Voltage | 380V/50HZ-60hz | |
| Rated Input Power | 4.5KW | Dimensions | 1300*400mm | |
| Wheel Diameter | 100mm | Frequency | 50HZ/60HZ | |
| Weight | 2000KG |
Product Description
China first class acrylic board polishing machine
We are manufacturers. As a manufacturer's advantage is:
To provide technical services at any time and the best price.
Application
It applies to high-grade acrylic products, precision polishing of crystal products,
product quality and product efficiency is very high, is one of the indispensable equipment
for production of high-grade acrylic/plexiglass/crystal products, especially perfect as light guide plate
After polishing by the diamond polishing machine, the surfaces are rather smooth , Bright as a mirror
the products are high transparent, non-discoloring .not any bubble or other deficiency caused
by traditional cloth wheel or flame polishing , not any streaks and scrap left by cutting machine.
Feature
1.High polishing precision, edge cutting depth is adjustable from 0-1mm. Low wastage of material.
2.After polished, the products are high transparent, non-discoloring. bright as a mirror.
3. Automatic polishing by machine, high efficiency, and save labor cost. A machine can save up
to dozens of workers.
4. Equipped with high power dust collector, environmental protection, no powder or flying debris
during working.
5. The whole design integration , easy to operate and maintain , Stable performance, minimun
breakdown, accurate feeding precision,long service life.
6. The machine is equipped with LED touch screen, which is controlled by PLC program.
Processing parameter can be adjusted according to material hardness and thickness.
7. The machine is also suitable for a certain angle of the material to be polished, to achieve
a multi-purpose machine.Polishing angle is adjustable in the range of 0-60 degree, more practical.
8. The machine adopts PCD cutting tools for fine processing acrylic, in order to achieve
the mirror effect.
9. The machine can cycle processing, unlimited working length, can polish super long work piece.
more suitable for batch processing
10. The equipment is equiped with frequency conversion electric spindle ,speed reducer ,
stable logic control circuit,greatly improves operation reliability and safety of the equipment.
11.Equipment with reliable performance, rational design, easy to operate, and high security,
high work efficiency.
Specification
Name | China first class acrylic board polishing machine |
Model No | DMS-1300W |
Suitable material | acrylic/plexiglass/PMMA/PC/PVC/ABS |
Max. Polishing Length Per Time | 1300mm(Support loop processing) |
Max. Cutting Thickness Per Time | 100mm |
Polishing Depth | 0mm--1mm( adjustable) |
Polishing Angle | 0-60 degree(adjustable) |
Max. Cutting Speed | 1000mm/Min |
The Best Cutting Speed | 600mm⁄min |
Cutting Mode | Spindle Feeding |
Rotation Speed | 6000-9000r/min (adjustable) |
Power Supply | 380V+/-10% , 50-60HZ |
Spindle Motor Power | 1.5KW |
Feeding Motor Power | 0.5Kw |
Gross Power | 4.5KW |
Dust Collector Mouth Diameter | 90mm |
Working Pressure | ≥0.5mpa |
Worktable size | 2180*400mm |
Machine Dimension | 2180*1090*1550mm |
Machine Weight | 2000KG |
After-sales service
1. One year quality guaranty. The machine with main parts (excluding the consumables)
Within the warranty period and the machine parts were damaged under normal using condition,
we will offer new parts for free.
2. Lifetime maintenance free of charge.
3. Free training course at our plant.
4. Before shipment,the Advertisement CNC Routerhave been tested,
we will take pictures and videos for you.
5.Electronic version of the english operation manual included with the Advertisement CNC Router
6. 24-hour technical support by email or calling.
