Home > Products > Automobile Wire > TXL XLPE insulation 16 guage automotive wire
TXL XLPE insulation 16 guage automotive wire
- Shanghai Port
- T/T
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Winpower | |
| Model Number | TXL 16AWG 26/0.254MM | Type | Insulated | |
| Application | Other, automotive wire | Conductor Material | Copper | |
| Conductor Type | Stranded | Insulation Material | PE |
Product Description
TXL XLPE insulation 16 guage automotive wire
Specifications: TXL automobile Wire 16AWG 26/0.254mm
Rated Temperature: 100 centigrade
Reference Standards: SAE J1128/1995 flame test
Conductor : 99.99% oxygen free copper conductor
Insulation: FR-XLPE , RoHS compliant
Application: internal wire in the car
Conductor | Insulation | DIELECTRIC STRENGTH (VAC,1MM) | ||||
AWG | Cross section (mm2) | Construction (No./mm) | DIA.(MM) | Thickness (mm) | O.D. (MM) | |
24 | 0.22 | 7/0.19 | 0.57 | 0.44 | 1.45 | 1000 |
22 | 0.35 | 7/0.25 | 0.75 | 0.43 | 1.60 | 1000 |
20 | 0.50 | 7/0.31 | 0.93 | 0.44 | 1.80 | 1000 |
18 | 0.80 | 16/0.254 | 1.17 | 0.44 | 2.05 | 1000 |
16 | 1 | 26/0.254 | 1.49 | 0.43 | 2.35 | 1000 |
14 | 2 | 19/0.36 | 1.80 | 0.43 | 2.65 | 1000 |
12 | 3 | 19/0.45 | 2.25 | 0.48 | 3.20 | 1000 |
10 | 5 | 19/0.57 | 2.85 | 0.53 | 3.90 | 1000 |
8 | 8 | 19/0.71 | 3.55 | 0.63 | 4.80 | 1000 |
Packing:to be packed in pe film and carton
Delivery: 3-15 days after receiving the down payment
Terms of payment:
T/T (30% down payment and pay off after receive the duplicate of B/L)
1. Sample Available
2. OEM are offered
3. Customer wire can be manfuactured
4. Convenient transportation path to Danyang
a.Take flight to Shanghai airport .About one hour by Harmony train from Shanghai Station to Danyang station.
b.Take flight to Changzhou airport.About 20 minutes by Harmony train from Changzhou station toDanyang station.
