2016 Most Pupular Hydraulic Shisha Charcoal Making Machine With 5% Discount

  2016 most pupular hydraulic shisha charcoal making machine

with 5% discount

Brief Introduction of hydraulic shisha charcoal making machine:

This type charcoal briquette press machine is a kind of the single-pressure -type automatic tablet press machine with powerful hydraulic pressure system. Hydraulic charcoal briquette machine is a kind of new designed shisha and BBQ charcoal briquette machine, which on the base of the mechanical type. There are two inductive contactors, by adjusting them we can make different size of briquettes.

It can press a variety of powder materials like charcoal powder, coal powder, cole powder, wood powder and other mineral powder into round, square ,hexgon or other shape tablets with high density. Especially, it is widely used in making charcoal briquettes field for shisha charcoal , BBQ charcoal. It is mainly exported to Middle East, Europe and other countries with a big annnual sales.

Technical Specifications of hydraulic shisha charcoal making machine:

1.Model: Hydraulic-48

2.Capacity: 48pieces/time; 5-8times/minute

3.Main motor for hydraulic oil pump: 11.0kw

4.Material feeding motor:  1.5kw

5.Discharge conveyor motor: 0.75kw

6.Press type: hydraulic

7.Pressure: 60-180tons (adjustble)

8.Size of final briquettes: 15-60mm(round); 15-60mm(square), or customized

9.Shape of final briquettes: square shape( 20*20*20mm;25*25*25mm;25*25*15mm), round shape (diameter:20,25,30,33,35,38,40,43mm), or customized.

10.Size of feeding materials: 0-3mm

11.Moisture of feeding materials: 10-15%

12.Control system: PLC control cabinet

13.Weight : 3500kg

14.Dimension: 3750*1200*2100mm

Features of hydraulic shisha charcoal making machine:

1 Special designed mandatory feeder. The machine can press pure powder material with feature of light weight and small density like charcoal powder.

2 Professional design makes the products high density, perfect appearance, no smoke and burning longer.

3 Humanization design or easy operating and maintaining.

4 Transmission system sealed in worm gear box below main body, is entirely separate independent component, it solves the mutual pollution, and the transmission system get lubrication sufficiently, also the noise and wear reduced.

5 The tablet briquette machine also can suitable in pharmacy, foodstuff, coal, chemical engineering, metallurgy building materials, refractory etc industry.

6 It uses quick burning charcoal technology. The outlet can burn from the top to down, firepower fierce, smokeless, tasteless, non-toxic, long burning time.

Mould can be customized and changable according to your needs:
