Automatic PET Bottle Energy Drink Filling Mechine / Mechinery / Equipment glass bottle
- 10 Set / Sets per Month
- port in China for PET Bottle Energy Drink Filling Mechine / Mechinery / Equipment
- T/T Credit Card
You May Like
-
User friendly Automatic PET Bottle Energy Drink Bottling Facility / Facilities / Instrument To Iraq
-
2000bph carbonated beverage filling machine
-
New design Automatic PET Bottle Beverage Filling Device
-
2016 new design Automatic PET Bottle Soda Water Washing Filling Capping Machine
-
Cost effective Automatic PET Bottle Carbonated Water Filling Machine
-
Factory produce Automatic PET Bottle Carbonated Drink Bottling Mechanical / Apparatus / Device
Product Details
Condition | New | Place of Origin | Jiangsu, China | |
Brand Name | SHEENSTAR | Model Number | DCGF14-12-5 | |
Voltage | 220V/380V | Power(W) | 3000W | |
Weight | 2000KG | Dimension(L*W*H) | 2080*1560*2130 | |
Processing Types | COLA,CARBONATED WATER,SODA WATER | Certification | BV CE ISO | |
Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Carbonate bottling machine
This Carbonated Water filling machine is mainly used in washing, filling and sealing gas containing beverage into bottles such as carbonated drink, cola, soft drinks ect.The machine is based on the introduction of foreign technology, combined with our years of
manufacturing experience. The machine combines filling and capping, with scientific and rational design, beautiful shape. It is Easy in
maintenance, with high automation. It is a automatic filling & capping machine.With high precision mechanical filling valves,our filling
machine stops vacuum when there are no bottles. This machine is equipped with external mechanical valve,inside which there is no
spring or sealing element. It makes use of combined transmission by open gear and gearbox,and adopts frequency conversion
stepless speed control,extending the speed modulating scope. It has an automatic lubricating device so that the lubrication points can
be automatically lubricated regularly in time.Also,our beer filling machine has high transmission efficiency,low noise and long life. In case of the blowout due to poor quality of the bottles during gas or beer filling,the filling valve will automatically close and the auto-cleaning device will work to treat the broken bottles.The sealer has the function of automatic reloading,which helps lower the bottle breakage.The movement of the beer bottle and capping heads is driven by electricity in order to fit bottles of different sizes.
Rinsing: grip the bottle neck, rotate filling plate, inverse bottle; internal rinsing and external spraying make bottles be cleaned completely.
Filling: counter pressure filling with holding bottle neck.
Capping: magnetic torque bottle holding type can minimize the cap damage rate and make the capping performance the best.
This machine owns the reasonable, stable and safe design. Under the condition that the bottle neck size is the same, only the output star wheel needs to be changed if bottles are different. It improves the efficiency a lot.
We are the carbonated machinery manufacturer from China.
main technical data
Model: | DCGF18-18-6 | DCGF24-24-8 | DCGF32-32-12 | DCGF40-40-12 | ||
Capacity :500ml | 5000 | 8000 | 12000 | 16000 | ||
Bottle shape: | roud or square | |||||
PET bottle: (mm) | (Bottle Diameter):φ50-.φ110mm (Height):150-340mm | |||||
Cap: | PE srew cap | |||||
Filling precision: | ≤±5mm | |||||
Filling pressure:(Mpa) | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 | ||
Rinsing pressure:(Mpa) | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 | ||
Filling volume :(L) | 3.5 | 4 | 6 | 8 | ||
Overall size:(mm) | 2450*1800 *2350 | 2780*2200 *2350 | 3600*2650 *2350 | 3800*2950 *2400 | ||
Weight: (kg) | 3500 | 4500 | 5500 | 6500 |
flow chart
products
The sample service
1.We can send you the video of the running machine.
2.You are welcome to come to visit our factory,and see the machine running.
3.If we get the permission of the customers who have bought the machines from us,we can provide you their contact information and you can go and visit.
Customized service
1.We can design the machines according your requirements(materil,power,filling type,the kinds of the bottles,and so on),at the same time we will give you our professional suggestion,as you know,we have been in this industry for many years.
2. We can offer free technical support and consultation such as design your factory,draw the factory layout and so on.
After-sales service
1.We will delivery the machine and provide the bill of load on time to make sure you can get the machine quickly
2.When you finish the Preparation conditions,our fast and professional aftersales service engineer team will go to your factory to install the machine,give you the operating manual,and train your employee until they can operate the machine well.
3. We often ask feedback and offer help to our customer whose machine have been used in their factory for some time.
4.We provide one year warranty with spare parts free
Zhangjiagang Sheenstar Technology Co., Ltd. has been specialized in the production of beverage machinery for many years. is a professional manufacturer of beverage packaging solutions. we have rich experience in manufacturing and maintenance.We supply water treatment, water filling production line, carbonated drink making filling production line, juice making filling production line, 5 gallon filling production line, labeling machine and shrink packing machine. With our machines, bottles can be plastic bottle, glass bottle barrel and cans.different sizes bottle from 100ML to 20L can be filled.
We are providing customized services to supply customers with the most suitable machine.
Cooperation Brand
To make the machine has a long life,and Reduce the maintenance,we buy the materials from famouse company,who has branch all over the world,and can quikly help you with some problems.
Ceritifications
we have been certificated by the famous cercification authority.The BV company and The alibaba can make sure that our factory can be trusted by you.
Company Management
Our company has different department to finish different things,the sales in our company has been trained about the machines ,they are professional to help you.
Production Capacity
We can produce 10 complete lines ,30 machines per month.
Quality Control
We have the single quality department,that make sure the material of the raw materials is good,and ensure the machine running smoothly.
Designed and Developed
According to the customer's requirements,and the beverage industry's development, The designing department design the most suitable machine for different area.The designing department make our company the leader of the beverage packing machine manufacture.
Export Market
Our machine has been sold to more than 40 countries,almost of the customers are satisfied with the machines and our service.
The Business Process
1. Inquiry-Pofessional Inquiry
2. Confirm the price, leadtime, payment term etc
3. Sheenstar sales send the proform invoice with sheenstar seal
4. Customer make the payment for deposit and send us bank receipt and offer samples
5. Inform customer has got the deposit and start to production
6. Middle production- send photos to show the production line which you can see your products in. Confirm the estimated delivery time again
7. Clients make payment for balance and Sheenstar ship the goods. Also can accept payment term-Balance against B/L Copy Or L/C payment Term. Inform the tracking number and check the status for clients.
8.Order can be say “finish” when you receive the goods and satisfy with them.
9. Feedback to Freedom about Quality , Service, Market Feedback & Suggestion. And we can do better.
Why choose SHEENSTAR?
Manufacture with many years experience
Stable high quality of machine
Competitive price
Fast,sincere and efficient service
Quality-packaging
1-year warranty
