sheenstar brand pe film packing machine

PE film wrapping machine

PE shrink wrapping machine

Product Description:
This machine is the last one of the beverage filling line to pack sleeve bottles together.

The instruction as follows:
1. Invert speed control.
2. Bottle entering, Auto unscrambling bottle, Pushing bottle, Heat sealing-Saw cutting, Pressing PE, Shrink, Cooling.
3. This machine applies air-stirring mechanism in pushing bottle and hot sealing-cool cutting. It uses flat silk pulse seal, the saw tooth knife cuts, The unique heat seal-cool cut mechanism, has guaranteed the packing agglutination, reliable, and artistic.
4. Automatic unscrambling bottle's appliance makes bottle changing more quickly and conveniently.
5. Delivering film mechanism and the tensity voluntarily adjusts.
6. PLC programmable procedure control system.

7. Double air blowers, guarantees the temperature balance in the shrink stove with PAD temperature controller, that apparently saves energy.
8. It applies wing shape stainless steel heating system, which is durable for long time use.
9. The heatproof Bolivian filament special fluorine dragon transportation net belt is used in shrink part to ensure the steady of transportation and high strengthen wear proof.
10. This machine applies invert speed control net belt conveying mechanism.
11. The height of the conveyer shall be made towards client's demand.
12. The direction of bottle entering can be adjusted according to client's demand
13, according customer request, can make the stainless steel belt inside the shrink tunnel instead of plastic belt

Maximum packing size: L]N=450ý00ý50mm(to be ordered)
Packing speed:12B/M
Machine Size: L]N=4700ý000ý700mm
Power:2KW
Power supply:220V 50HZ
Rated current:6A
Gas pressure:0.5-0.7Mpa
Suitable infrared thermo-wind circulation stove:
Vlotage:380V
Power:26KW
Transport speed:0-15m/min
Maximum Tunnel size: 1815ý00ý00mm
Machine dimension: L]N=3100ý600ý500mm

Remark:
1,If  customer  request  our  technicians  to  install  machines,  so  customer  need  pay  30USD/day,air  return  ticketsroom  and  meals.
2,Guarantee  period  is  15monthes  after  machines  received.
3,The  capacity  complete  depend  on  the  customer  demands  .We  welcome  customer  to  visit  our  company  !At  any  time  ,you  will  see  the  machine  working  and  running  in  our  factory  !
