Professional Perfect 5 Gallon / 5gallon Mineral / Water Bottle / Water Filling Machine
- port in China for 5 gallon / 5gallon mineral / water bottle / water filling machine
 - T/T Credit Card

You May Like
-


Cost Effective 20 Liter Portable Bottle Washing Machine
 -


Operate Flexibly 20 Liter Bottle Washing Machine
 -


Stable Operation 5 Gallon Barrelled Drinking Water Filling Machine / Filler
 -


Multiple Functions Full Automatic 5gallon Barrelled Water Line / Bottling Equipment
 -


Stable Operation Full Automatic 5gallon Barrelled Filling Machine / Filler
 -


Full Automatic 5gallon Barrelled Production Line / Equipment

Product Details
| Condition | New | Place of Origin | Jiangsu, China | |
| Brand Name | SHEENSTAR | Model Number | QGF-300 | |
| Voltage | 380V/50HZ | Power(W) | 3.8KW | |
| Weight | 1500kg | Processing Types | pure water, mineral water,spring water | |
| Certification | BV CE ISO | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Professional 5 gallon / 5gallon mineral / water bottle / water filling machine
This filling line specially produces 5 gallons bottled drinking water,
The machine is consisted of washer, filler and capper. The washer has several sprays which can be used as for both clean water rinsing and disinfectant rinsing. The disinfectant can be recycled. The machine also has automatic capping device, and cap rinsing device. The whole production line can automatic feeding barrel, rinsing, sterilizing, filling, capping, counting and output. In order to achieve the purpose of washing and sterilizing, bottle washer adopts multiple liquid injections washing and disinfectant spray, and washing solution can be used circularly. The sealer can seal bottle caps automatically. This filling line equips with water spraying device to sterilize caps of bottles in order to ensure those caps are aseptic and healthy.
Image show

Technical data
Model  | QGF-100  | QGF-300  | QGF-450  | QGF-900  | QGF-1200  |
Filling heads  | 1  | 2  | 3  | 8  | 12  |
Filling capacity  | 18.9  | 18.9  | 18.9  | 18.9  | 18.9  |
Barrel size(mm)  | ψ270×490  | ψ270×490  | ψ270×490  | ψ270×490  | ψ270×490  |
Production capacity(b/n)  | 100-120  | 200-240  | 300-400  | 900  | 1200  |
Gas pressure(Mpa)  | 0.4-0.6  | 0.4-06  | 0.6  | 0.6  | 0.6  |
Gas consumption(m³/min)  | 0.37  | 0.6  | 0.6  | 2.2  | 3  |
Motor power(kw)  | 1.75  | 3.22  | 4.8  | 8.5  | 8.5  |
Rated voltage(V)  | 380V/50Hz  | 380V/50Hz  | 380V/50Hz  | 380V/50Hz  | 380V/50Hz  |
Overall dimension(mm)  | 3790*650*1550  | 3550*800*1800 2800*1100*1800  | 3550*1200*1800 3800*1100*1800  | 2200*1860*2700 Not include cleaning  | 2560*2350*2750 Not include cleaning  |
The sample service
1.We can send you the video of the running machine.
2.You are welcome to come to visit our factory,and see the machine running.
3.If we get the permission of the customers who have bought the machines from us,we can provide you their contact information and you can go and visit.
Customized service
1.We can design the machines according your requirements(materil,power,filling type,the kinds of the bottles,and so on),at the same time we will give you our professional suggestion,as you know,we have been in this industry for many years.
2. We can offer free technical support and consultation such as design your factory,draw the factory layout and so on.
After-sales service
1.We will deliver the machine and provide the B/L on time to make sure you can get the machine
quickly.
2.When you finish the Preparation conditions,our fast and professional aftersales service engineer team will go to your factory to install the machine,give you the operating manual,and train your employee until they can operate the machine well.
3. We often ask feedback and offer help to our customer whose machine have been used in their factory for some time.
4.We provide one year warranty with spare parts free and life time technical support.



Why choose SHEENSTAR?
Stable high quality of machine
Competitive price
Fast,sincere and efficient service
Quality-packaging
1-year warranty
