3&5 Gallon Bottle Filling Machine
- port in China for 3&5 gallon bottle filling machine
 - T/T Credit Card

You May Like
-


Perfect 5 Gallon Pure / Purified / Distilled Water Filling Machine
 -


Operate Flexibly Perfect 20 Liter Bottled Water Filling Machine / Line
 -


Automatic Barrel Drink Production Line
 -


High Performance Perfect 3~5 Gallon / 3 / 5 Gallon Drinking Water Filling Machine
 -


Sheenstar Perfect Barrel Water Filling Plant / Machinery
 -


Factory Produce Barrel Drink Production Line / Equipment / Machine

Product Details
| Condition | New | Place of Origin | Jiangsu, China | |
| Brand Name | SHEENSTAR | Model Number | QGF-600 | |
| Voltage | 380V/50HZ | Power(W) | 7.5KW | |
| Weight | 3000kg | Processing Types | pure water, mineral water,spring water | |
| Certification | BV CE ISO | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
3&5 gallon bottle filling machine
Our 5 gallon water filling machine is suitable for 3 gallon barrel, 5 gallon barrel, and 6 gallon barrel, and can be used for filling mineral water, pure water, etc. The machine is PLC controlled, full automatic working, filling volume and filling time can be adjustable. All machines are made of Stainless steel SUS304 , and the surface of the machine is well polished, easily for future cleaning.
All the pipeline, valve, is made of stainless steel, other necessary PVC parts are food grade. We can design the producing capacity according to customer requirement, the rinsing, filling head can be from 1-16, during rinsing process, the barrel will be rinsing by hot
alkali, disinfecting water, and then pure water, to ensure every corner of the bottle is well cleaned.5. Cylinder-pushing structure is
widely used in our bottle feeding, bottle filling, and bottle capping system, and the whole process is automatically. All the pump used in our producing line is stainless steel material. No bottles no rinsing, no bottle no filling, no bottles no capping
Image show

Technical data
Model  | QGF-100  | QGF-300  | QGF-450  | QGF-900  | QGF-1200  |
Filling heads  | 1  | 2  | 3  | 8  | 12  |
Filling capacity  | 18.9  | 18.9  | 18.9  | 18.9  | 18.9  |
Barrel size(mm)  | ψ270×490  | ψ270×490  | ψ270×490  | ψ270×490  | ψ270×490  |
Production capacity(b/n)  | 100-120  | 200-240  | 300-400  | 900  | 1200  |
Gas pressure(Mpa)  | 0.4-0.6  | 0.4-06  | 0.6  | 0.6  | 0.6  |
Gas consumption(m³/min)  | 0.37  | 0.6  | 0.6  | 2.2  | 3  |
Motor power(kw)  | 1.75  | 3.22  | 4.8  | 8.5  | 8.5  |
Rated voltage(V)  | 380V/50Hz  | 380V/50Hz  | 380V/50Hz  | 380V/50Hz  | 380V/50Hz  |
Overall dimension(mm)  | 3790*650*1550  | 3550*800*1800 2800*1100*1800  | 3550*1200*1800 3800*1100*1800  | 2200*1860*2700 Not include cleaning  | 2560*2350*2750 Not include cleaning  |


The sample service
1.We can send you the video of the running machine.
2.You are welcome to come to visit our factory,and see the machine running.
3.If we get the permission of the customers who have bought the machines from us,we can provide you their contact imformation and you can go and visit.
Customized service
1.We can design the machines according your requirements(materil,power,filling type,the kinds of the bottles,and so on),at the same time we will give you our
professional suggestion,as you know,we have been in this industry for many years.
2. We can offer free technical support and consultation such as design your factory,draw the factory layout
and so on.
After-sales service
1.We will delivery the machine and provide the bill of load on time to make sure you can get the machine
quickly
2.When you finish the Preparation conditions,our fast and professional after service engineer team will go to
your factory to install the machine,give you the operating manual,and train your employee until they can
operate the machine well.
3. We often ask feedback and offer help to our customer whose machine have been used in their factory
for some time.
4.We provide one year warranty with spare parts free

Why choose SHEENSTAR?
Stable high quality of machine
Competitive price
Fast,sincere and efficient service
Quality-packaging
1-year warranty
