Product Details
| Place of Origin | Liaoning, China | Brand Name | Pro, PRO | |
| Model Number | 610/303, PR914-610/PRO240 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Automatic Control Arch Roof Sheet Making Roll Forming Machine
l Technical Parameter of PR-914-610
Dimension : 8900mm X 22300mm X 2300mm (Single axle & 4 tires)
Total Weight : About 8Ton
Bending Leaf : 10mm thickness, processed by CNC
Cutting blade : 12CrMoV material, Heat treatment
Cutting type : Mechanical Cutting
Forming type: Roll-formed and length-set cutting.
Total motor power : 19.7KW
Main Motor Power : 7.5KW
Bending Power : 3.0KW+1.5KW x 2
Cutting Power : 4.0KW
Seaming Power: 1.1KW+1.1KW
Roller Material : 45# high-quality steel, quenched HRC 55~65, hard chrome plating.
Shaft Material : 45# high-quality steel, galvanized
Bearing : Made in Harbin
Stand of molding : 13+1
Rolling material: Width : Feeding width :914mm
Effective width : 610mm
Using rate : 66.7%
Thickness : 0.8-1.5mm
Working Speed : Forming Part : 15m/min
Bending Part: 13m/min
Seaming : 16m/min
Suitable width : 12~42m
De-coiler : Inner-diameter of coil : 450mm ~ 650mm,
Max width of coil : 914mm ~ 934mm Load : 10Ton
l Design drawing
- Picture of detail
- Picture of project
- Model list
Model
| Feeding width (mm) | Effective width (mm) | Use ratio | Rolling thickness (mm) | Capable width | Suitable width |
PR-600-305 | 600 | 305 | 50.8% | 0.6-1.5 | 4-28 | 4.8-22 |
PR-600-300 | 600 | 300 | 50% | 0.6-1.5 | 4-30 | 4.8-24 |
PR-914-400 | 914 | 400 | 43.7% | 0.8-1.5 | 4-40 | 12-25 |
PR-914-610 | 914 | 610 | 66.7% | 0.8-1.5 | 4-38 | 6-32 |
PR-914-650 | 914 | 650 | 71.1% | 0.8-1.5 | 4-26 | 6-30 |
PR-914-700 | 914 | 700 | 76.5% | 0.8-1.5 | 4-22 | 6-22 |
PR-914-750 | 914 | 750 | 82% | 0.8-1.5 | 4-14 | 6-20 |
PR-1000-610 | 1000 | 610 | 61% | 0.9-1.5 | 5-42 | 10-32 |
PR-1000-680 | 1000 | 680 | 68% | 0.9-1.5 | 5-38 | 10-30 |
PR-1000-700 | 1000 | 700 | 70% | 0.9-1.5 | 5-30 | 10-20 |
PR-1000-750 | 1000 | 750 | 75% | 0.9-1.5 | 5-24 | 10-18 |
PR-1000-800 | 1000 | 800 | 80% | 0.9-1.5 | 5-18 | 10-16 |
PR-1200-800 | 1200 | 800 | 66.7% | 1.2-1.5 | 6-42 | 7.5-35 |
PR-1220-800 | 1220 | 800 | 65.5% | 1.2-1.5 | 6-45 | 7.5-35 |
PR-1250-800 | 1250 | 800 | 64% | 1.2-1.5 | 6-50 | 7.5-35 |
