Tower Crane(qtz63)

FOB Price

US$ 30,000 - 45,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	construction projects
Place of Origin	Beijing, China	Brand Name	JH
Model Number	QTZ63	Warranty	one year
After-sales Service Provided	Engineers available to service machinery overseas

The tower crane is a combination of advanced technologies of the present day. It is equipped with a

hydraulic self-raising mechanism and a frequency-converting slewing mechanism.

The electric control system of the tower crane adopts the advanced “PLC + frequency converter”

control mode of the present day, which has realized the stepless speed regulation and greatly

improves the reliability, maneuverability and stability of the control system and the work efficiency of

the tower crane.

The tower crane is equipped with all kinds of reliable safety devices, such as hoisting height limiter,

slewing range limiter and multifunctional limiter to control the load moment, hoisting capacity and

trolley traveling range. Its PLC (Programmable Logic Controller) unit can diagnose the cause of

breakdowns.

The use of world-famous electric components such as OMRON, YASKAWA, Schneider (TE) and MEAN WELL greatly

reduces the failure rate of the electric control system and improves the work efficiency of the users.

Besides, there are also electric safety devices like anemoscopes and obstacle lights and mechanical

safety devices to prevent the breaking of trolley axles and wireropes.

Model	QTZ63B(5610)	QTZ63B(5013)
Jib Length (M)	56	50
Free Height (M)	41	41
Max. Possible Height (M)	161	161
Max. Load (T)	6	6
Tip Load (T)	1.0	1.3
Wall-attached Device for Max Height (sets)	6	6
Main Material (mm)	Standard Mast Section 135×135×10 (Square Steel Tube) Reinforcing Mast Section 135×135×12 (Square Steel Tube)	Standard Mast Section 135×135×10 (Square Steel Tube) Reinforcing Mast Section 135×135×12 (Square Steel Tube)
Mast Section Dimension (m)	1.835×1.835 ×2.5	1.835×1.835 ×2.5
Hoisting Speed (a=2) (m/min)	80/40/10	80/40/10
Min. Stable Falling Speed (m/min)	5	5
Slewing Speed (r/min)	0-0.62	0-0.62
Radius-changing Speed (m/min)	40/20	40/20
Jacking-up Speed (m/min)	0.6	0.6
Total Motor Power (kw)	55.2	55.2
Power Supply	380V/50HZ	380V/50HZ
Weight of Independent Structure (T)	36.80	36.80
Counterweight (T)	14.85	14.85
Base Form	Embedded Type (Outrigger Stationary)	Embedded Type (Outrigger Stationary)
Number of Containers Needed for Shipment (Free Height)	6 * 40HC containers	6 * 40HC containers
