Good Price Heated Circulator for Industries

Product model

UC-A2530

Temp. range

50 ~300℃ ℃

Controller

PID adaptive control

Temp. Control optional

Heat-conducting medium outlet ntrol

Communication protocol

MODBUS RTU Protocol, RS 485 Interface

Temp. accuracy

±0.5℃

Heating power

25kW

Circulation pump

Max110L/min
2.5BAR

Heater

Orient electric heater

Independent
Temperature limiter

LNEYA

Operation panel

Display setting temperature and testing temperature;Touch screen display

Safety protection

Self-diagnosis function; freezer overload protection; high pressure switch, overload relay, thermal protection device,
liquid low level protection, high temperature protection and temperature fault protection.

Closed
circulation system

The whole system is full closed circulation,there is no oil mist at high temperature and no water vapor at low temperature,
pressure do not rise up when system is running.The system will supplement oil automatically at low temperature.

Connection size

DN-25

Dimension

700*800*1650

Weight

195kg

Power

AC 380V 50HZ
26.5kW (max)

Case material

Cold rolled steel

Optional

Optional 7-inch color touch screen controller,temperature curve record,data export to excel format.

Optional

SUS304 case material

Optional power

220V 60HZ three-phase,440V~480V 60HZ three-phase
