EXPANSION COMPENSATORS HOUSED EXPANSION JOINTS
Negotiable
1 (Min. Order)
- Shanghai
You May Like
Product Details
| Material | Carbon Steel | Type | Other, threaded ends flanged ends welded ends | |
| Place of Origin | Jiangsu, China | Connection | Welding |
Product Description
This expansion joint is designed for axial movement only. Pipe must be properly guided and anchored per the recommendations of the Expansion Joint Manufacturers Association.
Design Data:
Temp. 750° F. (399° C)
Press. 175 PSI, (1206 K Pa(g))
Test Press. 250 PSI, (1809 K Pa(g))
2″ Compression, (50mm) •Axial Movement 1/2″ Expansion, (13mm)
Material: Bellows-Multi-Ply S.S. T304 Other Parts – Carbon Steel
Ends Type:
1. Weld Ends (Carbon Steel Body, 304 Stainless Steel Bellows)
2. Thread Ends (Carbon Steel Body, 304 Stainless Steel Bellows)
3. Flanged Ends (Carbon Steel Body, 304 Stainless Steel Bellows)
4. Groove Ends (Carbon Steel Body, 304 Stainless Steel Bellows)
| 2 inches of compression | ||||
| Model Number | Pipe Size | Overall Length | Pipe OD | |
| inch | mm | |||
| HYSC20075 | 3/4" | 324 | 1.05 | 26.7 |
| HYSC20100 | 1" | 336 | 1.31 | 33.3 |
| HYSC20125 | 1-1/4" | 336 | 1.66 | 42.2 |
| HYSC20150 | 1-1/2" | 370 | 1.9 | 48.3 |
| HYSC20200 | 2" | 370 | 2.375 | 60.3 |
| HYSC20250 | 2-1/2" | 406 | 2.88 | 73.2 |
| HYSC20300 | 3" | 406 | 3.5 | 88.9 |
| HYSC20400 | 4" | 416 | 4.5 | 114.3 |
| 3 inches of compression | ||||
| Model Number | Pipe Size | Overall Length | Pipe OD | |
| inch | mm | |||
| HYSC30075 | 3/4" | 419 | 1.05 | 26.7 |
| HYSC30100 | 1" | 419 | 1.31 | 33.3 |
| HYSC30125 | 1-1/4" | 419 | 1.66 | 42.2 |
| HYSC30150 | 1-1/2" | 445 | 1.9 | 48.3 |
| HYSC30200 | 2" | 445 | 2.375 | 60.3 |
| HYSC30250 | 2-1/2" | 476 | 2.88 | 73.2 |
| HYSC30300 | 3" | 489 | 3.5 | 88.9 |
| HYSC30400 | 4" | 489 | 4.5 | 114.3 |
| Description | Materials | |||
| Hose Bellows | Stainless Steel | |||
| NPT End | Carbon Steel Sch40 | |||
| Else | Carbon Steel | |||
