Olive Oil Filling Capping and Packing Machine

Specifications

Olive oil filling capping and packing machine
1.Filling capacity:800-40000b/h
2.Filling size:0.5L-25L
3.CE ISO

Introduction:

This type of machine can be used for fixed amount small package filling,straight line type filling, metical, electric, apparatus control of all sorts of viscous and no viscous,erosive liquid,such as plant oil chemical,liquid,daily chemical industry.It is rather simple and rapid to change items,the design is quite distinct,the property is Very advantageous,its appearance corresponds to international concept for mechanical equipment.

Main Features:

1. Adopts piston pump to fill, suitable for all kinds of liquid, high precision; The structure of pump adopts shortcut dismantling organ, convenient to wash, sterilize.
2. The piston ring of volumetric injection pump use different material of silicone, polyclonal or other kinds according to liquid characteristic, use ceramic pump in special industry.
3. PLC control system, frequency conversion adjusting speed, high degree automation.
4. No bottle, no filling, auto count the quantity. And have the anti-drop device.
5. Filling quantity of all pumps is adjusted in a lump, minim adjustable for each pump. Easy and quick operate.
6. Filling head is equipped with anti-dropping equipment, diving to the bottom to fill, rise slowly, to avoid bubble.
7. The whole machine is suitable bottles in different size, easy adjusting, and can be finished in short time.

Models:

Detailed features:

1.It has applied SIEMENS PLC computerized control,from Germany.
2.It has intellectual,protection function.
3.Vacuum drop prevention device guarantees there Should be absolutely no drop or leakage during production.
4.There is a switch for step progressive type suppiy and continuous supply.It can be Set Optionally.
5.It has applied imported pneumatic control parts.
6.It has applied German technique on photoelectric sensors.
7.National patented double speed technique has greatly increased production efficiency.
8.This machine is suitable for many items,the adjustment is rapid and high efficient.
9.Electrical volume adjustment System.
10.Photoelectric inspection system has applied TURCK products of Germany

11.Our company have the wide selection of beverage filling machines.

12.According to your requirements,we will provide the ideal machine for you.

13.The oil filling machine can used in production edible oil And it suit PET bottles.

14.Every machine is designed by professional designer with beautiful appearance,convenient control

15.The main machine adopts advanced PLC control,Touch screen and no-bottle,no-cap system.

16.The Key electric elementsare from famous international brand.So it will achieve the authentic full-automation.

Pictures:
