(Manufactory) quad band GPS/GSM Antenna JCB062 with SMB
USD $1 - $4
/ Piece
100 Pieces(Min.Order)
- 10 Piece / Pieces per Month
- SHANGHAI
- T/T Credit Card PayPal
You May Like
-
(Manufactory) Galileo/GLONASS GPS&GSM Combination Antenna JCB014with MMCX
-
(Manufactory) Free sample high gain car navigation GPS/GSM Combo Antenna for tracker/car gps antenna
-
Dual Band GPS+GSM Antenna
-
(Manufactory) Dual Band gps gsm combo antenna
-
Screw mount GPS+GSM Combination Antenna
-
High Gain Dual Band GPS GSM Antenna
Product Details
| Place of Origin | Zhejiang, China | Brand Name | JIASHANJINCHANG | |
| Model Number | JCB062 |
Product Description
Specifications
GPS+GSM combi Antenna:Frequency: 1575.42Mhz; 900/1800Mhz
VSWR: 1.5:1
LNA gain: 28
Certification:ROSH CE ISO9000 TS1694
1.Electrical Characteristics
1.1 Dielectric Antenna
Form 1
No. | Item | Specifications | Post Environmental Tolerance |
1 | Center Frequency | 1575.42 MHz | ±3 MHz |
2 | Band Width | ±5 MHz | ±1 MHz |
3 | V.S.W.R(in BW) | 1.5:1 | — |
4 | Gain(Zenith) | 3 dB | ±0.5 dB |
5 | Polarization | RHCP | — |
6 | Impedance | 50 Ω | — |
1.2 LNA/Filter
Form 2
No. | Item | Specifications | Post Environmental Tolerance |
1 | LNA Gain | 28±2 dB | ±2.5 dB |
2 | Noise Figure | 1.5 dB | — |
3 | Filter Out Band Attenuation | 12dB Min f0+50MHz 16dB Min f0-50MHz | ±1.0 dB |
4 | DC Voltage | 2.2~5 V | |
5 | DC Current | 5~15 mA | |
1.3 GSM Antenna
Form 3
No. | Item | Specifications |
1 | Frequency | 824~960 MHz/1710~1990 MHz |
2 | V.S.W.R(5m) | ≤2.:1 |
3 | Gain(Zenith) | 2 dBi |
4 | Impedance | 50 Ω |
1.4 Mechanical
Form4
No. | Item | Specification |
1 | Cable | RG174 3m or others |
2 | Connector | SMB |
3 | Plastic Housing | Black |
4 | Mounting | Screw |
.
