127um 16ch fiber array
- shanghai
- T/T
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | tianxing | |
| Model Number | 16ch fiber array |
Product Description
127um 16ch fiber array
1. Feature
---High precise fiber core-to-core accuracy
---Low insertion loss and high reliability
---High precise angle polish and customer product available
---Wide Operating Temperature: From -40°C to 85°C
2. Application
---Planner lightwave circuit splitter devices
---Array waveguide grating (AWG)
---Arrayed active and passive fiber devices
---MEMS devices
---Multi-channel micro-optics modules
| Parameter | |
| Material | Quartz, Pyrex or Silicon |
| No. of Channel | 2, 4, 8, 16, 32,64,128 |
| V-groove pitch (μm) | 250, 127 / 0.7 |
| Fiber Array Length (m) | 2.0±0.1 |
| Polishing Angel (°) | 0,+8, -8 (±0.3) |
| Polishing Flatness | < 5 fringes@633nm |
| Fiber Type | SMF-28e or SMF-28e XB |
| Operating Temperature (°C) | -40~+85 |
| No. of Channel | Core Spacing (μm) | L(mm) | W(mm) | H(mm) | h(mm) |
| 2 | 250 | 10.8 | 2.5 | 2.8 | 1.5 |
| 4 | 250 | 10.8 | 2.5 | 2.8 | 1.5 |
| 8 | 127 | 10.8 | 2.5 | 2.8 | 1.5 |
| 8 | 250 | 12.5 | 2.8 | 2.8 | 1.5 |
| 16 | 127 | 11.3 | 3.75 | 2.8 | 1.5 |
| 32 | 127 | 11.3 | 5.5 | 2.8 | 1.5 |
| 32 | 127 | 11.3 | 5.5 | 2.8 | 1.5 |
| 64 | 127 | 12.5 | 11 | 2.8 | 1.5 |
We sincerely welcome all interested buyers to visit our factory and contact us directly for further information, we will reply you as soon as possible!
