50KW Weifang series Diesel Generator set
- Qingdao port of China
- Credit Card
You May Like
-
China Diesel Generator 50KW with battery breaker
-
factory use back up generator 50kw price
-
three phase soundproof 15kw generator diesel
-
12KVA Silent Diesel Generator with ISO
-
170KW China generator price with Weichai engine
-
180 kw diesel generator set brushless generator 225kva weifang weichai 6 cylinder
Product Details
| Place of Origin | Shandong, China | Brand Name | HUAQUAN | |
| Model Number | HQBL50GF | Output Type | AC Three Phase | |
| Speed | 1500r/minj | Frequency | 50Hz | |
| Rated Power | 50KW/63KVA | Rated Voltage | 400/230V | |
| Rated Current | 90A |
Product Description
50KW Weifang series Diesel Generator set
Product Information
Parameters
| 50KW DIESEL GENERATOR DETAILS | |||
| Model | HQBL50GF | Start Method | DC 24 |
| Generator Prime Power(KW/KVA) | 50/63 | Output Current(A) | 90 |
| Standby Power(KW/KVA) | 55/69 | Voltage(V) | 400/230 |
| Power Factor | 0.8 | Phase | Three phase, Four Wires |
| Frequency(Hz) | 50 | Weight(kg) | 850 |
| Size(mm) | L | W | G |
| 1800 | 700 | 1600 | |
| Diesel Engine Data | |||
| Manufacturer | Ricardo Engine | Model | R4105ZD |
| Rated Speed(Rpm) | 1500 | Diesel Engine Max Power(KW/H) | 56 |
| Cylinder No. | 4 | Arrangement Type | In-line |
| Bore×Stroke(mm) | 105×115 | Displacement(L) | 4.33 |
| Intake Method | Turbocharged | Compression ratio | 17.0:1 |
| Fuel | Diesel Fuel | Full Load Consumption(g/kw.h) | ≤228 |
| Oil Capacity(L) | 13 | Start Method | Electrical |
| Engine Cooled Method | Radiator Max 40℃,fans are driven by belt with safety guard. | ||
| Alternator Data | |||
| Manufacturer | China Stanford | Model | XN50 |
| Rated Power(KW/KVA) | 50/63 | Excitation Type | Brushless |
| Insulation Class | H | Protection Grade | IP22 |
| Unload Voltage Adjustment | ≥±5% | Stable Voltage Adjustment | ±1% |
| Efficiency (%) | 94.8 | Voltage Control Method | AVR |
Details of Our Products
Certifications
Our Company
About us
About Our Company
1. Offer the main Power range from 10kva~1500kva.
2. Adopt the famous engines like Weichai engines, Deutz engines, Steyr engines, Cummins engines, Perkins engines, Isuzu engines, Ricardo engines, Changchai engines, Yuchai engines, Jichai engines etc. These are widely used all over the word.
3. We only adopt standard high-level quality alternator, to produce the high-level diesel generators.
4. We offer Open-generators, Silent-Generators, Automatic-Generators and Trailer-Generators.
5. All spare parts serviced directly by our company.
6. We are confirmed as the OEM factory by many those engine factories and alternator factories.
Our experience
We specialized in producing diesel generators. We have exported to many countries and widely used in domestic.
1. Exported countries: Nigeria, Indonesia, Malaysia, Philippine, North Korea, Ghana, Gabon, South Africa, Guinea, Russia, Iraq, Iran, Colombia, Burkina Faso, Liberia, Zambia, etc.2. Domestic: Send to most of the cities in china, and get high praise from my clients
Sales Promises
Huaquan provides a full line of brand new and high quality products.Each
and every unit is strictly factory tested Warranty is according to our
standard conditions:12 months or 1000 running hour’s ,subject to the
earlier one .Service and parts are available from our factory
1.What's your power range of Generators?
Answer: We can offer the range from 10kva~1000kva.
2.What's your delivery time?
Answer: Generally,we can delivery in 7 days after we get the deposit.
3.What's your payment?
Answer: We accept T/T ,and 30% as the deposit,the balance payment should be paid before shipping.
4.What's your warranty?
Answer: All our products we offer on year warranty.
5.What's your MOQ?
Answer:We accept the MOQ is 1 set.
