Steel Cord Conveyor Belt
USD $100 - $1,000
/ Ton
20 Tons(Min.Order)
- 1000 Ton / Tons per Month
- Xingang
- T/T
You May Like
Product Details
| Condition | New | Type | Bucket Conveyor | |
| Material | Rubber | Material Feature | Heat Resistant | |
| Structure | Belt Conveyor | Place of Origin | Hebei, China | |
| Brand Name | EIT | Model Number | 1800S |
Product Description
Specifications
1.High tensile strength2.Small elongation in use
3.lesser elongation in use
4.Good troughabilit
Steel Cord Conveyor Belt
Steel cordconveyor belt 1.High tensile strength 2.Small elongation in use 3.lesser elongation in use 4.Good troughabilit
Steel cord conveyor belt:
Specification:
| ST630 | ST800 | ST1000 | ST1250 | ST1600 | ST2000 | ST2500 | ST3150 | ST3500 | ST4000 | ST4500 | ST5000 | ST5400 | ST6300 | |
| Tensile Strength (N/mm) | 630 | 800 | 1000 | 1250 | 1600 | 2000 | 2500 | 3150 | 3500 | 4000 | 4500 | 5000 | 5400 | 6300 |
| Max Diameter of Cord(mm) | 3 | 3.5 | 4 | 4.5 | 5 | 6 | 7.5 | 8.1 | 8.6 | 8.9/ | 9.7 | 10.9 | 11.3 | 12.3 |
| Pitch of Cord(mm) | 10 | 10 | 12 | 12 | 12 | 12 | 15 | 15 | 15 | 15 | 16 | 17 | 17 | 18 |
| Top Rubber Cover Thickness (mm) | 5 | 5 | 6 | 6 | 6 | 8 | 8 | 8 | 8 | 8 | 8 | 8.5 | 9 | 10 |
| Bottom Rubber Cover Thickness (mm) | 5 | 5 | 6 | 6 | 6 | 8 | 8 | 8 | 8 | 8 | 8 | 8.5 | 9 | 10 |
| Width (mm) | Cord Number | |||||||||||||
| 800 | 75 | 75 | 63 | 63 | 63 | 63 | 50 | 50 | 50 | |||||
| 1000 | 95 | 95 | 79 | 79 | 79 | 79 | 64 | 64 | 64 | 64 | 59 | 55 | 55 | 54 |
| 1200 | 113 | 113 | 94 | 94 | 94 | 94 | 76 | 76 | 77 | 77 | 71 | 66 | 66 | 63 |
| 1400 | 133 | 133 | 111 | 111 | 111 | 111 | 89 | 89 | 90 | 90 | 84 | 78 | 78 | 74 |
| 1600 | 151 | 151 | 126 | 126 | 126 | 126 | 101 | 101 | 104 | 104 | 96 | 90 | 90 | 85 |
| 1800 | 171 | 143 | 143 | 143 | 143 | 114 | 114 | 117 | 117 | 109 | 102 | 102 | 96 | |
| 2000 | 159 | 159 | 159 | 159 | 128 | 128 | 130 | 130 | 121 | 113 | 113 | 107 | ||
| 2200 | 176 | 141 | 141 | 144 | 144 | 134 | 125 | 125 | 118 | |||||
| 2400 | 193 | 155 | 155 | 157 | 157 | 146 | 137 | 137 | 129 | |||||
| 2600 | 209 | 168 | 168 | 170 | 170 | 159 | 149 | 149 | 140 | |||||
| 2800 | 184 | 184 | 171 | 161 | 161 | |||||||||
Cover rubber property and grades :
| Test items | Property indexes | |||||||
GB9770-2001 | DIN22131 | |||||||
D | H | L | P | W | X | Y | ||
Tdnsile strngth | Mpa >= | 18 | 25 | 20 | 14 | 18 | 25 | 20 |
Pull to break the elongation rate | % >= | 400 | 450 | 400 | 350 | 400 | 450 | 400 |
after aging(70°C,7D) Change rate of tensile strength Change rate of elongation | % | -25~+25 | -25~+25 | -25~+25 | 25~+25 | -25~+25 | -25~+25 | -25~+25 |
Abrasion | <= | 90MM3 | 120MM3 | 150MM3 | 200MM3 | 90MM3 | 120MM3 | 150mm3 |
