Rip Resistant Steel Cord Belting

FOB Price

US$ 50 - 100 / Meter

100 Meters(Min. Order)

Port XINGANG NINGBO SHANGHAI
Payment TermsT/T D/P D/A

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Gravity Conveyor
Material	Rubber	Material Feature	Heat Resistant
Structure	Belt Conveyor	Load Capacity	800KGS to 1500kgs
Place of Origin	Hebei, China	Brand Name	ORACLE,SUPER FLEX,
Model Number	EP80-100-125-150-200-250-300

Product Description

Specifications

rip resistant steel cord belting
PVG & PVC,belt width 200-2400MM
NN100,NN150,NN200,NN300
Durable,resistance of oil,acid,alkal

rip resistant steel cord belting

Useage:
It is mainly applicable for the underground well haulage of coal mines, and also the conveyance of materials for metallurgical and chemical industries. The whole core fire-retardant conveyer belt is divided into two types: PVC, PVG..

PVC type conveyer belt's upper and lower layers are PVC coating cover, single-sided tape thickness: ≥1.0mm; PVG type belt's upper and lower layers are nitrile rubber and PVC, single-sided tape thickness: 1.5mm-4.5mm.

PVC type conveyer belt's inclined angle: <16°;

PVG conveyer belt's inclined angle: <20°.

Type and technical parameter of PVC conveyer belt:

Standard MT914-2008						Safety factor 10(Breaking strength*1/10)
The Slope <16°C						Safety factor 10(Breaking strength*1/10)
Standard type	Degree	Breaking strength≥,N/mm		Tensile yield≥,%		Advising Mindiameter of Transmission Drum
Standard type	Degree	Longitudinal	Transverse	Longitudinal	Transverse	Advising Mindiameter of Transmission Drum
680S	4th	680	265	15	18	320
800S	5th	800	280			400
1000S	6th	1000	300			500
1250S	7th	1250	350			500
1400S	8th	1400	350			630
1600S	8th	1600	400			750

Type and technical parameter of PVC conveyer belt:

Standard MT914-2008 BS3289 HG2805						Safety factor 10(Breaking strength*1/10)
Standard type	Degree	The slope <20°C				Recommend minimum roller diameter
		Breaking strength≥,N/mm		Tensile yield≥,%
		Longitudinal	Transverse	Longitudinal	Transverse
680S	4th	680	265	15	18	400
800S	5th	800	280			500
1000S	6th	1000	300			630
1250S	7th	1250	350			750
1400S	8th	1400	350			750
1600s	9th	1600	400			750

Safe function:

Function Name	The alcohol combustion	The propane combustion	Electrical conductivity	The roller rub
Standard value	Average value≤3S,List value≤10S(Have no cover gum)	a)≥600	≤3X10⁸Ω	≤325°C
Standard value	Average value≤5S,List value≤15S(Have no cover gum)	b)≥50mm;≤140°C≤1250mm	≤3X10⁸Ω	Have no Mars
