PVC Insulated terminal / wire terminal

FOB Price

USD $0.08 - $0.15 / Bag

20000 Bags(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China		Brand Name	TENGEN OR OEM
Model Number	E2512		Type	Crimp Terminal

1.PVC or Nylon material with Copper or Brass
2.CE,ROHS, ISO certificate
3.Copper or Brass plated Tin , Silver material

Insulated terminal, wire terminal, insulated cord end terminal,terminal, connection terminal,PVC terminal, Nylon terminal

Margin temperature105 Ui=300V Material:Copper / Brass
ITEM NO	Dimension (mm)						A.W.G mm²	Color of Insulating Terminal upGermany / downFrance
	F	L	W	DΦ	CΦ	A.W.G
E0506	6.0	12.0	2.6	1.3	1.0	#22	0.5	orange white
E0508	8.0	14.0
E0510	10.0	16.0
E7506	6.0	12.4	2.8	1.5	1.2	#20	0.75	white blue
E7508	8.0	14.6
E7510	10.0	16.4
E7512	12.0	18.4
E876	6.0	12.4	3.0	1.7	1.4	#18	1.0	yellow red
E878	8.0	14.6
E1010	10.0	16.4
E1012	12.0	18.4
E1508	8.0	14.6	3.5	2.0	1.7	#16	1.5	red black
E1510	10.0	16.4
E1518	18.0	24.4
E2508	8.0	15.2	4.0	2.6	2.3	#14	2.5	blue gray
E2512	12.0	19.0
E2518	18.0	25.0
E4009	9.0	16.5	4.4	3.2	2.8	#12	4.0	gray orange
E4012	12.0	19.5
E4018	18.0	25.5
E6012	12.0	20.0	6.3	3.9	3.5	#10	6.0	black green
E6018	18.0	26.0
E10-12	12.0	21.5	7.6	4.9	4.5	#7	10.0	ivory brown
E10-18	18.0	27.5
E16-12	12.0	22.2	8.8	6.2	5.8	#5	16.0	green ivory
E16-18	18.0	28.2
E25-16	16.0	29.0	11.2	7.9	7.5	#4	25.0	brown black
E25-22	22.0	35.0
E35-16	16.0	30.0	12.7	8.7	8.3	#2	35.0	taupe
E35-25	25.0	39.0
E50-20	20.0	36.0	15.3	10.9	10.3	#1	50.0	olive

Margin temperature105 Ui=300V Material:Copper / Brass
ITEMNO	CONDUCTOR	Dimension mm)						Color
ITEMNO	CONDUCTOR	F	L	W	B	DΦ	CΦ	Germany	France
TE 0508	2 x 0.5	8	14.5	8	6.5	1.8	1.5	white	white
TE 7508	2 x 0.75	8	14.7	8	6.7	2.1	1.8	blue	gray
TE 7510	2 x 0.75	10	16.7	10	6.7	2.1	1.8	blue	gray
TE 1008	2 x 1.0	8	15.1	8	7.1	2.3	2.0	red	red
TE 1010	2 x 1.0	10	17.1	10	7.1	2.3	2.0	red	red
TE 1508	2 x 1.5	8	15.5	8	7.2	2.6	2.3	black	yellow
TE 1512	2 x 1.5	12	19.5	12	7.5	2.6	2.3	black	yellow
TE 2510	2 x 2.5	10	18.5	10	8.5	3.3	2.9	gray	blue
TE 2513	2 x 2.5	13	21.5	13	8.5	3.3	2.9	gray	blue
TE 4012	2 x 4.0	12	23.1	12	11.1	4.2	3.8	orange	gray
TE 6014	2 x 6.0	14	26.1	14	12.1	5.3	4.9	green	yellow
TE 10 - 14	2 x 10.0	14	26.6	14	12.0	6.9	6.5	brown	red
TE 16 -14	2 x 16.0	14	31.3	8.9	17.3	8.7	8.3	ivory	blue
