INST new products 1565nm return optical receiver 1000w optical laser source
- 10000 Piece / Pieces per Month
- shenzhen
- T/T Credit Card
You May Like
-
INST new products 1563nm return optical receiver 1000w optical laser source
-
INST new products 1526nm return optical receiver 1000w optical laser source
-
INST new products 1550.12nm return optical receiver 1000w optical laser source
-
INST new products return optical receiver 1000w optical laser source
-
INST C-Band high efficiency 1550nm EDFA
-
INST C-Band high efficiency edfa price
Product Details
| Place of Origin | Guangdong, China | Brand Name | INST | |
| Model Number | professional Amplifier |
Product Description
INST new products 1565nm return optical receiver 1000w optical laser source
parameters | unit | Min. | typical | Max. |
Wave length range | nm | 1528 |
| 1563 |
Input peak power | dBm | -20 | 1 | 10 |
Output peak power* | W | - |
| 100 |
Pulse width* | ns | 1 | 10 | 200 |
Repeated frequency* | kHz | - | 500 | - |
PDG | dB |
|
| 0.5 |
PMD | ps |
|
| 0.5 |
Input isolation | dB | 45.0 |
|
|
Output isolation | dB | 45.0 |
|
|
Operating temperature | ℃ | -20 |
| +65 |
Operating humidity | % |
|
| 90 |
Noise figure | dB | <5.0 | ||
Storage temperature | ℃ | -40 |
| +85 |
Power supply |
| DC+5V GND(Module) | ||
Optical connector |
| FC/APC or customization | ||
In&out pigtail fiber |
| SMF28 | ||
INST is a professional high quality industrial optical fiber amplifier manufacturer and a customized light source and mold provider. Our specialty is high quality and connection to customers specifications. At the same time, we provide different series of plus and sockets and various finger scanners.
INST has exported various amplifier, light source and mold to different of electrical devices and industrial equipment manufactures around the world.
Our vision: to be the most respected manufacturer.
A1: 1.100% high quality, all failed parts get free warranty within 30 days after received.
2.Accept 10 years warranty upon customer requirement.
3.Repairs parts are available within 10years; We will inform the EOL products to you from time to time.
Q2: What if the amplifier which we need have some differences on specifications from yours?
A2: Any difference, we can design and produce according to your requests, which includecolor, material, processing requirement etc.
Q3: How can I get a sample to check your quality?
A3: After price confirmation, you can require for sample to check our quality. Sample is free, but the freight charge should be paid.
