Home > Products > Optical-fiber light source products > INST the Device Highlights Greater DFB Narrow--band Optical Network Line Terminal
INST the Device Highlights Greater DFB Narrow--band Optical Network Line Terminal
- shenzhen
- T/T Credit Card
You May Like
-
INST 1550nm Ultra-Narrow Linewidth Semicondator Laser Source
-
INST L-Band ,S-Band High Power Narrow Linewidth Laser Source
-
INST Semiconductor Laser Marking Machine/pump Laser Source
-
INST 1310nm Infrared Fiber Coupled DFB Laser Source
-
INST Distributed Feedback Lasers DFB Laser Source
-
INST The Device Highlights Greater Narrow Band Light Source
Product Details
| Place of Origin | Guangdong, China | Brand Name | INST | |
| Model Number | DFB |
Product Description
INST the device highlights greater DFB Narrow--band optical network line terminal
Parameters | Min. | Typical | Max. | Unit |
Operating wavelength | 770 | 780 | 790 | nm |
Output power | 0 | - | 10 | dBm |
Spectral band (The room temperature) | 0.1 | - | 5 | KHz |
Short term power stability(single temperature) | - | 0.02 | - | dB |
Long term power stability(single temperature) | - | 0.05 | - | dB |
Power stability of all operating temperature | - | - | 5 | % |
Operating temperature | -40 | - | 60 | ℃ |
Storage temperature | -40 | - | 85 | ℃ |
Relative humidity | 5 | - | 90 | % |
Dimensions(L*W*H) | The size of module or desktop can be costumed |
| ||
Power supply | module(5V DC); Desktop(220V AC or 48V DC) | |||
Electric connector | module(26PIN Mini port); Desktop(Many Kinds of port) | |||
Pigtail fiber type | SMF or MMF | |||
Optical connector | FC/APC or other | |||
Pigtail fiber length | 1.2±0.2m(can be substituted by flange output) | |||
INST is a professional high quality industrial laser light source manufacturer and a customized Electric connector and mold provider. Our specialty is accurate and connection to customers specifications. At the same time, we provide different series of fiber optic amplifier and ASE light source and various SLD light source.
INST has exported various waterproof connectors, harnesses, cable, plugs and sockets and mold to different of electrical devices and industrial equipment manufactures around the world.
Our vision: to be the most respected manufacturer.
A1: 1.100% high quality, all failed parts get free warranty within 30 days after received.
2.Accept 10 years warranty upon customer requirement.
3.Repairs parts are available within 10years; We will inform the EOL products to you from time to time.
Q2: What if the laser source which we need have some differences on specifications from yours?
A2: Any difference, we can design and produce according to your requests, which includecolor, material, processing requirement etc.
Q3: How can I get a sample to check your quality?
A3: After price confirmation, you can require for sample to check our quality. Sample is free, but the freight charge should be paid.
C-Ba
l LIDAR
l B-OTDR temperature and pressure sensor
l The oil and gas exploration
l leak detection and monitoring
l The coherent optical communication
l The optical measurement and test
l The distributed fiber Bragg grating sensor
INST the device highlights greater DFB Narrow--band optical network line terminal
INST the device highlights greater DFB Narrow--band optical network line terminal
INST the device highlights greater DFB Narrow--band optical network line terminal
al
