4 Port PCIe Lan Card With Intel I350AM4 Chipset 4xRJ45 PCI Express x4 Gigabit For Server Support VDMq

LREC9714HT

4 Port PCIe Lan Card With Intel I350AM4 Chipset 4xRJ45 PCI Express x4 Gigabit For Server Support VDMq

4 port Gigabit PCI-E Ethernet lan card designed with performance enhancing features and new power management technologies

Description:

The new LREC9714HT 4 Port PCI Lan Card builds on LR-LINK’s history of excellence.LR-LINK continues its market leadership with this new generation of PCIe* GbE network adapters.Built with the bridgeless Intel® Ethernet Controller I350, these adapters represent the next step in the Gigabit Ethernet (GbE) networking evolution for the enterprise and data center by introducing new levels of performance through industry-leading enhancements for both virtualized and iSCSI Unified Networking environments.This new family of adapters also includes new power management technologies such as Energy Efficient Ethernet (EEE) and DMA Coalescing (DMAC).

Key Features:

*  Halogen-free 4 port Gigabit PCI-E lan card with copper interface options

*  Innovative power management features including Energy Efficient Ethernet (EEE) and DMA Coalescing for increased efficiency and reduced power consumption

*  Flexible I/O virtualization for port partitioning and quality of service (QoS) of up to 32 virtual ports

*  Scalable iSCSI performance delivering cost-effective SAN connectivity

*  High-performing bridgeless design supporting PCI Express* Gen 2.1 5GT/s

*  Reliable and proven Gigabit Ethernet technology from Intel Corporation

*  Software Tools and Management

*  Intel® Ethernet Controller I350

*  Low-Profile and Standard height full

*  IEEE* 802.3 auto-negotiation

*  1Gb/s Ethernet IEEE 802.3, 802.3u, 802.3ab PHY specifications Compliant

*  Integrated PHY for 10/100/1000 Mb/s for multispeed, full, and half-duplex

*  IEEE 802.3x and 802.3z compliant flow control support with software-controllable Rx thresholds and Tx pause frames

* Automatic cross-over detection function (MDI/MDI-X)

*  IEEE 1588 protocol and 802.1AS implementation

*  Preboot eXecution Environment (PXE) flash interface support

The 4 Port PCI-e Lan Card Picture Showing:

The 4 Port PCI-e Lan Card  other features:

*  Plug and play specification support

*  Intel® I/O Acceleration Technology (Intel® I/OAT)

*  Ships with full-height bracket installed; low-profile bracket included in package

*  Power Management Protocol Offload (Proxying)

*  Eight transmit (Tx) and receive (Rx) queue pairs per port

*  Traffic Isolation andTraffic Steering

*  VM to VM Packet forwarding (Packet Loopback)

*  MAC and VLAN anti-spoofing

*  Malicious driver detection

*  Independent Function Level Reset (FLR) for Physical and Virtual Functions

*  IEEE 802.1q Virtual Local Area Network (VLAN) support with VLAN tag insertion, stripping and packet filtering for up to 4096 VLAN tags

*  Support for Simple VEPA

*  VF Promiscuous modes

*  Legacy and Message Signal Interrupt (MSI) Modes

*  Message Signal Interrupt Extension (MSI-X)

*  Intelligent interrupt generation

*  Receive Side Scaling (RSS) for Windows environment

*  Support for packets up to 9.5K Bytes ( Jumbo Frames)

*  Header/packet data split in receive

*  PCIe v2.1 TLP Processing Hint Requester

*  Management Component Transport Protocol (MCTP)

*  Firmware Based Thermal Management

*  IEEE 802.3 MII Management Interface

*  Extended error reporting

*  Controller Memory Protection

*  Vital Product Data (VPD) Support

Order information:

PS: The above details are only for reference,if there are any changes,no inform will have.
