Automatic UV coating machine
USD $35,000 - $55,000
/ Unit
1 Unit(Min.Order)
- 50 Unit / Units per Month
- Shanghai
You May Like
Product Details
| Condition | New | Type | Other, Coating machine | |
| Automatic Grade | Automatic | Place of Origin | Shanghai, China | |
| Brand Name | TOWIN | Model Number | ZUV/ZUVA SERIES |
Product Description
Specifications
Coating machine1. CE certificate
2. High efficiency and stability
3. Low rate of paper waste
4. Save varnish
ZUV/ZUVA SERIES AUTOMATIC UV COATING MACHINE
Features:
1. Safety operation: CE Certification.
2. High efficiency: Equipped with high speed feeder for non-stop paper feeding and delivery, pneumatic opening type curing chamber and cylinder block head, this machine can work in high stability.
3. Low rate of waste: When sheets jam, the machine will stop automatically.
4. Varnish consumption saved: Reverse roller will control the varnish quantity to make the sheet surface coated smoothly.
5. Wide range of paper: Air knife system is suitable for light paper of 80-600gsm.
Options:
PLC control system
Lengthened conveyor of 2000mm or 4000mm can be optional.
Technical specifications:
| Model: | 650A | 920A | 1200A |
| Max. Sheet Size(mm) | 520X650 | 1100X920 | 1100X1200 |
| Min. Sheet Size(mm) | 250X330 | 307X400 | 307x440 |
| Max. Speed(pcs/h) | 5000 | 5000 | 5000 |
| Sheets weight(gsm) | 80-600 | 80-600 | 80-600 |
| UV Lamp power | 5.6KW x 3 | 8KW x 3 | 9.75KW x 3 |
| IR Lamp power: | 1.2Kw x 18pcs | 1.5KWx18pcs | 1.8KW x 18 |
| Total Power(kw) | 37 | 44 | 54 |
| Weight(t) | 3.5 | 4.1 | 4.6 |
| Dimension(mm) | 9920X1300X1600 | 9920X1580X1600 | 9920X1800X1600 |
