Network h 264 Cms Free Software 8CH Standalone AHD Dvr

FOB Price

US$ 30.00 - 30.00 / Piece

1 Piece(Min. Order)

Port shenzheng
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	GM
Model Number	HY-NH-3608

Product Description

Network h 264 cms free software 8CH standalone AHD dvr

SPECIFICATIONS
No-Alarm Model	Model	8 Channel H.264 AHD-NH	8 Channel H.264 AHD-NH
		HY-NH-3608W (A,K,R,L,M,Y,P,J,Q,D,S,Z)	HY-NH-3608TQ (L,M,Y,J)
	Board model	PCBA-HY-NH-8286-8	PCBA-HY-NH-T8286-8
System	Main processor	Industrial grade embedded micro controller chip Taiwan Zhiyuan chipset GM8286
	Operating system	Embedded LINUX operating system
	System resource	Multi-channel real-time recording synchronously, multi-channel real-time playback, multi-channel multi-user network operation, USB back up.
Display	Operation interface	16 bit real color GUI interface support mouse operation
	Multilingual Language	YES, 25 kinds of language
	Display screen	1/4/8/9 screen
Video	Video Standard	PAL / NTSC(1080N)
	Image encode	H.264(Main Profile)
	Capture function	YES
	Monitor quality	Monitor:D1; VGA & HDMI: (19201080,12801024,1280720,1024768)
	Playback quality	1080N/720P
	Encode capability	8ch 1080N@20fps	8ch 1080N@20fps
	Decode capability	4ch 1080N@12fps	4ch 1080N@12fps
	Multi-Input (ONVIF 2.8)	Analogue:8ch 1080N	Analogue:8ch 1080N
		Analogue+ Network HD:1080N(AHD-NH)4+720P(network)4	Analogue+ Network HD:1080N(AHD-NH)4+720P(network)4
		Network:8*720P(network)	Network:8*720P(network)
Audio	Audio compression	G.711A
Record and playback	Record mode	Manual, alarm, motion detection, timing
	Local playback	1--4ch (local mode)
	Video search	Time, date, event, channel search
Storage and back up	Space Usage	Video 720P:10G~42G/daychannel,1080P:20G~80G/daychannel,Audio 691.2M/day *channel
	Video storage	Local Hard Disk, Network
	Back up mode	Network backup, USB portable HDD
Interface	Video input	8ch BNC(1.0Vp-p,75Ω)
	Video output	1ch CVBS, 1ch VGA, 1ch HDMI	1ch CVBS, 1ch VGA, 1ch HDMI
	Audio input	4ch RCA (200-2800mV,30KΩ)	1ch RCA (200-2800mV,30KΩ)
	Audio output	1ch RCA (200-3000mV,5KΩ)/1ch HDMI audio output
	Alarm input	NO
	Alarm output	NO
	Network port	1*RJ45 10/100 Base-T self-adaptive Ethernet port
	PTZ control	1*RS485 port, Support more than 20 kinds protocols.	NO
	USB port	Support USB 2.0 port
	HDD port	Accommodates 1 SATA HDDs (1 HDD capacity up to 4TB)
	Wireless Port	3G & WIFI ( Extented by USB)	3G & WIFI ( Extented by USB)
User	User level	Admin / User
	User right	Users can set different permissions (How to use please refer to the manual book)
	Password protection	YES
Remote	Remote Independent Operation	YES
	Download records	YES
	Remote Event Trigger Recording	YES
	CMS	CMS Software for multiple DVR (up to 255 DVR simultaneously)
	Browser	Internet Explorer, Mozilla Firefox, Google Chrome, Safari
	Live Audio	YES
	On-line user	Max. 10
	Mobile Surveillance	YES (supporting iPad, iPhone & Android;iPad, iPhone, Andriod remote playback)
	Network Protocol	DHCP, PPPOE, FTP, DDNS, NTP, UPNP, EMAIL, IP authority, 3G, Wireless settings
Alarm	Motion detection	16 × 12 grids per channel;6 adjustable parameters for accurate detection(for local analog channel only)
	Event Notification	FTP / E-Mail
	Pre-alarm Recording	YES
	Video loss	Video loss notification
	Buzzer	YES	NO
Others	IR remote controller	Remotely control DVR and PTZ cameras via IR transmitter (IR receiver built-in)
	Remote control	YES
	Cooling fan	NO
	Tour	YES
	Power Source (±10%)	DC 12V / 2A
	Power Consumption (±10%)	<10W(without HDD)
	Operating Temperature	0℃ ~ +55℃
	Dimensions (mm) **	250mm(L)* 210mm(W)* 45mm(H)
	System Recovery	System auto recovery after power failure
Package	Net Weight	0.93kg±0.1kg
	Carton Box Size	5units packing:358mm(L)* 83mm(W)* 270mm(H); 10units packing:325mm(L)* 80mm(W)*255mm(H) ;
	Package Size	5units packing:440mm(L)* 375mm(W)285mm(H) ; 10units packing:415mm(L) 335mm(W)*525mm(H) ;
	Gross Weight	5units packing:7.5kg±0.5kg; 10units packing:14.0kg±0.5kg;

Packaging & Shipping

Carton Box Size : 5units packing:358mm(L)* 83mm(W)* 270mm(H); 10units packing:325mm(L)* 80mm(W)*255mm(H) ;

package size :5units packing:440mm(L)* 375mm(W)*285mm(H) ; 10units packing:415mm(L)* 335mm(W)*525mm(H) ;

photo show
