Tyre Recycling Machine for Rubber Powder & Used Tire Recycling Plant
- Qingdao port
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | HUALONG | |
| Model Number | XKP-400/450/560 | Type | Other, tyre recycling machine |
Product Description
Specifications
Process is simple and practical.We have the patent technology.
ISO9001, CE
Recycling Tire Machine Waste Tire Recycling Machine
Product Description
1. granule made by the desulfurization process will be reclaimed rubber production sheet material used in the manufacture of machine pads, roadbed mat, cushion etc. Various washers, fenderboard, sound-absorbing materials not high demand of the mechanical properties of low-grade products.
2. Color elastic floor tile, elderly and young children in sports field laid, to the safety of adults and children play good protection. The biggest characteristic is to: prevent slippery, shock absorption, wear-resisting, antistatic, sound insulation, sound insulation, every tide, lie between cold, heat insulation, do not glance, water resistant, fire, non-toxic, no radiation, strong weatherability, anti-aging, long life, easy to clean, easy construction, etc.
3. Production waterproofing materials, waterproofing paint, waterproof and sealed material, etc.
4. Road alignment materials, rubber granule modified asphalt pavement of high grade highway and the runways in developed countries has entered the practical stage, and have developed rapidly.
5. Used for modified asphalt, made modified asphalt pavement pavement abrasion resistance, spalling resistance, resistance to wear greatly improve life for ordinary pavement 2 -- 3 times, lower pavement maintenance costs 30-50%.
6. Used to build plastic sports venues, runway, artificial turf.
7. For track rails add concrete prefabricated mixing added before adding the required to add a certain proportion of all kinds of high-grade USES concrete products, direct casting forming. At present is used to manufacture the train rails and special occasions fence, special occasions such as the base.
8. Anointed highway highway caulking caulking cream special rubber granule and asphalt, asphalt oil, packing and condensation of dry and wet agent whatever are blending good bonding, with the product fill aperture fill sex, resistance with water resistance, spalling resistance, greatly improve the tensile properties and winter summer anti melts variable performance increased by 40%.
9. With a rubber granule manufacture for shoe soles, according to a certain proportion, directly after joining mixed refine used to neutralize all kinds of sole.
Tire recycling machine related equipment:
We manufacture two kinds for rubber granule production machine.
1.Manual waste tire recycling machine
Small-scale production 200-500kg per hour
Production equipment from waste tire decomposition equipment, crushing machine, magnetic powder screening 3 major components conveying unit. Through the waste tire decomposition QQJ-20, QTJ-380 equipment QKJ-45 380, YQJ-285, first, tires processed into small pieces of 3.5 centimeters square; Then the pulverizer set XKP - 400/450/560 type to glue block broken wire mixed powder grinding get, granule; Then by magnetic powder conveying unit screening CSF9000 type, steel wire and tire rubber separation thoroughly. Through the belt conveyor device after two ways of fine sieve bed screen then through magnetic material roller, magnetic separation separating out wire, making 10 mesh fineness 40 mesh fineness of pure powder (either). Short of asks mesh fineness of feeding conveyor returns by blocks of powder, the cycle again grinding mill grind technology is advanced, does not need any chemical raw materials, no gas, no wastewater, the operating cost is low. Magnetic separation wire effect 80Kw attain 99.9%, keeping the average processing a ton of tyre power-hungry 200 degrees or so, output per hour for 200 to 500 kilograms (powder fineness has different, yield also have different) is the use of steel wire tyre production the best equipment powder.
Manual waste tire recycling machine plan 200-500 kg/h

Use tire wire drawing machine draw wire, put tire into the tire crusher, process 5cm*5cm pieces, put pieces into rubber granule production line make 15-30 mesh powder
Automatic waste tire recycling machine plan 1500 kg/h
waste tire recycling split machine
Technical Parameter
| Ring Cutter | QQJ-20 | Strip Cutter | QTJ-380 |
| Motor power(KW) | 5.5 | Motor power(KW) | 5.55 |
| Rotate speed(r/min) | 46.8 | Disc diameter (mm) | 380 |
| Tube diameter | 1200 | Rotate speed(r/min) | 18.4 |
| Size: (L*W*H) | 110*900*1700 | Size (L*W*H) | 1290*870*1550 |
| Block Cutter | QKJ-45 | Press Loop Machine | YQJ-285 |
| Motor power(KW) | 11 | Motor power(KW) | 15 |
| Rotate speed (r/min) | 420 | Former roller linear speed(m/min) | 15.5 |
| Outside diameter of cutter | 200 | Rotate speed (r/min) | 18.4 |
| Size (L*W*H) | 1130*830*1100 | Size (L*W*H) | 1520*1150*1210 |
Tire wire drawing machine
Technical Parameter
| Model | 1200Y |
| Motor Power (kw) | 7.5 |
| Capacity (tires/h) | 80-100 |
| Overall Dimensions (L×W×H) | 4700×900×1700 |
| Weight (T) | 2.8 |
Tire shredder
Technical Parameter
| Type | LP-400 | LP-800 | LP-1200 |
| Quantity of cutter head | 10 | 16 | 20 |
| Dimension of cutter head (diameter*thickness)mm | 300*35 | 460*50 | 560*50 |
| Size of charge-in(mm) | 400 | 800 | 1200 |
| Size of charge-out(mm) | 35 | 50*50 | 50*50 |
| Handling Capacity (t/h) | 700 | 1500 | 3000 |
| Motor Power (kw) | 35 | 40*2 | 60*2 |
| Dimension(m) | 2.1×0.9×1.9 | 4200×2100×2300 | 6000×2800×3700 |
| Weight (T) | 1 | 8 | 16 |
Rubber powder production line
| screen (big) |
| Conveyor belt (magnetic separation) (big) |
| Vibrating screen (small) |
| Conveyor belt (magnetic separation) (small) |
| Main conveyor belt (big) |
Rubber crusher
It is waste tire recycling main machine
Technical Parameter
| Type | XKP-400 | XKP-450 | XKP-560 |
| Front roll diameter(mm) | 400 | 450 | 560 |
| Rear roll diameter(mm) | 400(Groove roller) | 450(Groove roller) | 560(Groove roller) |
| Working length of rolls(mm) | 600 | 650 | 800 |
| Front roll surface speed(m/min) | 17.32 | 23.2 | 25.56 |
| Friction ratio | 1:1.38 | 1:1.38 | 1:1.30 |
| Max. nip (mm) | 8 | 8 | 15 |
| Motor power | 45 | 55 | 90 |
| Size: L×W×H(mm) | 3950×1800×1780 | 4770×1846×1835 | 5064×2284×1978 |
Fiber separator
Technical Parameter
| Parameter | 1100×8 |
| Impeller number | 8 |
| Impeller diameter | 1100mm |
| Speed of main shaft | 377 or 464/min |
| Power | 5.5kw |
| Speed of feeder | 29 r/min |
| Feeder power | 0.4kw |
| Overall dimension | 1600xH3400(mm) |
Fine powder machine
Processing equipment
Rubber technology exhibition
Company Information
Qingdao Shenghualong Rubber Machinery Co., Ltd is the biggest and best rubber machinery factory in Qingdao,China. As one of main manufacturers engaging on manufacturing rubber machinery in Qingdao Area, taking "Product quality first and client's credit standing uppermost" as corporate faith, the company strictly carries out inner management, wins markets depending on high-quality products and satisfies client's demands with lower price, excellent after-sale service and full varieties. Therefore, it has been appraised as "Qingdao Municipal Advanced Unit on Both Material & Spiritual Civilizations Constructing" for successive years and "Contract-stressing and Promise-keeping Unit" by Qingdao city for successive thirty years.
The company adopting advanced manufacturing technics and detection instruments, manufacture waste tire recycling machienry, rubber granule production line, reclaimed rubber machinery, tyre machinery, rubber vulcanizing machine, rubber extruder, rubber cooling line, rubber refining machinery, rubber strainer etc. Products are exported to India, Russia, the united Arab emirates, Iran, Egypt, the United States, Mexico, Brazil, Turkey, Indonesia, Malaysia, etc. All over the world. tire recycling machine
