Home > Products > Milling Machine > KX3S siemens 808d system educational used mini cnc milling machine
KX3S siemens 808d system educational used mini cnc milling machine
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Place of Origin | Shanghai, China | |
| Brand Name | linuo | Model Number | KX3S | |
| Type | Vertical | CNC or Not | CNC | |
| Voltage | 380V | Power(W) | 1000w | |
| Dimension(L*W*H) | 1280*895*1845mm | Weight | 380kg | |
| Certification | CE | Warranty | one year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
KX3S siemens 808d system educational used mini cnc milling machine
Introduction:
-Worktable size--550x160 mm
-PC based CNC sytem,high reliability
-Automatic lubrication system
| KX3S | ||
| TABLE | Table size | 550×160mm |
| T slot (amount×width×distance) | 3×12mm×43mm | |
| Max. load | 30kg | |
| TRAVEL | X travel | 280mm |
| Y travel | 120mm | |
| Z travel | 270mm | |
| Spindle nose to table | 80-350mm | |
| Spindle center to column | 200mm | |
| SPINDLE | Spindle taper | MT3/NT3/R8 |
| Spindle motor | 1000w | |
| Spindle speed | 100-5000r/min | |
| FEED(STEPPER) | The max moving speed | 2000mm/min |
| The max feeding speed | 500mm/min | |
| Power of X/Y | 4Nm | |
| Power of Z | 6Nm | |
| FEED(SERVO) | The max moving speed | 5000mm/min |
| The max feeding speed | 1000mm/min | |
| Power of X/Y | 400W | |
| Power of Z | 750W | |
| ACCURACY | Positioning accuracy | 0.015mm |
| Repeatability accuracy | 0.01mm | |
| OTHERS | Power | 230/120V |
| Weight(NW/GW) | 380/460kg | |
| Overall dimension | 1280×895×1845mm | |
| Packing size | 1420×1060×2035mm | |
Lianyungang Linuo Machine Tool Co.,ltd is a leading high-tech enterprise and manufacture in China for High end machine tools, has strong technical team covering full technical field.
which is specializes in exporting all kinds of machinery,such as grinding machines,CNC machine centers,CNC & universal lathes,CNC & universal milling machines,radial drilling machines,and cnc wire cutting edm machines etc.
Lianyungang Linuo Trading Co.,ltd is a Import & Export company,which is the branch company for international business.
We sincerely hope to establish a long-term cooperative relationship with you and become your true partner when you need our service.
