Home > Products > bearing housing with seals > Conveyor Roller Bearing Housing 89*204
Conveyor Roller Bearing Housing 89*204
- XINGANG
- T/T
You May Like
Product Details
| Place of Origin | Hebei, China | Brand Name | HXT | |
| Model Number | 108*190*25mm |
Product Description
Steel Roller Bearing Housing 89*204
Roller D(mm) | Housing OD(mm) | Bearing No | Axle/Shaft D(mm) |
D89 | D84 | 204/205 | D20/25 |
D108 | D102.8 | 204/205/305/306 | D20/25/30 |
D133 | D128 | 205/305/306 | D25/30 |
D159 | D153 | 305/306/308 | D25/30/40 |
D194 | D188 | 308/310 | D40/50 |
D217 | D211 | 308/310 | D40/50 |
Belt Conveyor Impact Roller Features:
a) Diameter range: 76mm-219mm, other diameters available on request.
b) Pipe length: From 180mm-3500mm
c) Material: Pipe, Q235 equal to S235JR(DIN); Shaft, 45# STEEL (GB) equal to C45(DIN)
d) Bearing: deep groove ball and double sealing bearing 2RZ and 2Z with C3 clearance
e) Sealing: multi-stage labyrinth seals achieve waterproof and dust proof
f) Lubrication: Grease is Lithium soap type grease with Rust Inhibitors, grease is permanent lubricant.
g) Color: roller surface could be painted any color as per customer request.
h) Each roller would be through strict inspection and test to ensure every out coming roller is of true high quality.
We can support series of conveyor idler(roller)/pulley/bearing housing with labyrinth seals!
We will quote to you as your specific information or as drawing
