Product Details

Shaft coupling for torque transmission and damping of torsional vibrations
Axial plug-in - easy assembly - maintenance free

Rotex flexible coupling.

Model	Bore	D	L	L1	F	E	M	Wrench Torque	Rated torque	Max torque	Max rotational frenquency (rpm)	static tcrsional stiffness (Nm/rad)	Weight
TS6-16	4,5,6 6.35,8	16	27	8.5	3	9.5	M3	0.7N.m	0.8N.m	1.6	20000	100	8g
TS6-20	6,6.35,8 9.525,10,12	20	29	8.5	3	12.5	M3	0.7N.m	1.5N.m	3	15000	160	12g
TS6-25	6,6.35,8 9.525,10,12	25	34	10.5	4	15	M4	1.7N.m	2N.m	4	13000	220	28g
TS6-32	8.9.525 10,12,14	32	38	11.5	4	21	M4	1.7N.m	2.5N.m	5	10000	310	46g
TS6-32L	8.9.525 10,12,14	32	49	11.5	4	21	M4	1.7N.m	2.5N.m	5	10000	310	52g
TS6-40	10,11,12 14,15,16	40	51	12.5	4.5	27	M5	4N.m	10N.m	20	8000	520	88g
TS6-55	12,14,15 16,19	55	57	13.5	5	40	M6	7N.m	25N.m	50	6000	850	180g

Product characteristics

Shaft coupling for torque transmission and damping of torsional vibrations
Axial plug-in - easy assembly - maintenance free
Operative range from -50ºC to +120ºC, peak temperature up to +150ºC
Compensation for axial, radial and angular shaft misalignments
large base programme from stock:
- finish bore acc. to ISO fit H7 and feather key groove acc.
to DIN 6885 sheet 1-JS9
- spline toothings acc. to DIN and SAE
- inch and taper bores
Explosion protection rated and confirmed acc. to EG Directive 94/9/EG
